John Deere 755C Series II
Series: John Deere Crawler Loader
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
John Deere crawler loaders 350 to 855 – from Dubuque since 1958: the size classes 350, 450, 555, 655, 755 and 855, generations B to K, 31 to 149 kW
The crawler loader – a track undercarriage with a front bucket instead of a dozer blade – is an American speciality that loads in civil engineering, basement excavation, recycling and landfills where wheel loaders find no grip. John Deere has built them since 1958 at its Dubuque, Iowa plant and is, with Caterpillar, the last major supplier of the class. The number logic is the same as for the dozers: 350 and 355 the small class, 450 and 455 the medium, 555, 655 and 755 the big crawler loaders, 855 the heaviest; the letters B, C, D, G, J and K are generations from the 1970s to the K series of the 2010s. The 605 and 700J models in the register are dozers of the same series logic that the sorting placed here – LGP stands for Low Ground Pressure with wide tracks, XLT for the long-undercarriage version.
Read on 3 more paragraphs
The register lists 22 versions with 31.3 to 149.1 kW from three- to six-cylinders of 2,688 to 10,144 cm³ – Deere 300 series in the small, 4045 and 6068 in the medium, PowerTech PVX 6068 in the younger models – at rated speeds of 1,800 to 2,500 rpm, torque from 149 to 990 Nm and operating weights from 5,538 to 22,498 kg.
Deere's crawler loaders are known for the hydrostatic drive from the G series onward, which allows stepless turning under load, and for the four-in-one bucket that combines loading, grading, grabbing and pushing in one tool.
On used machines, operating hours, wear of tracks, rollers and sprockets (undercarriage costs dominate the calculation), play in the lift arm, leak-free hydraulics and the condition of the hydrostatic drive are what count.
Sources: Kennwerte der Modelle John Deere Laderaupen, John Deere Crawler Loaders (Hersteller)
Technical data
Engine
| Engine model | D 926 T-EA2correct |
|---|---|
| Power | 132 kWcorrect |
| Rated speed | 1,800 rpmcorrect |
| Torque | 919.2correct |
| Speed at max. torque | 1,000 rpmcorrect |
| Cylinders | 6correct |
| Displacement | 9,996.1 cm³correct |
| Aspiration | turbochargedcorrect |
| Coolant capacity | 57.9 lcorrect |
| Engine oil capacity | 22 lcorrect |
Dimensions and weights
| Ground clearance | 426.7correct |
|---|---|
| Unladen weight | 21,001.3 kgcorrect |
Drivetrain and chassis
| Top speed | 10.9 km/hcorrect |
|---|
Working data
| Pump flow | 208.2 l/mincorrect |
|---|---|
| Hydraulic oil capacity | 174.9 lcorrect |
| Hydraulic pressure | 259.9correct |
| Fuel tank capacity | 319.9 lcorrect |
Other data
| Cab height | 3,304correct |
|---|---|
| System voltage | 24 Vcorrect |
Where this model stands
Power-to-weight ratio: 6.3 kW/t (132 kW / 21 t)
Stronger than 67% of the wheel loaders in the register — out of 1,251 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the John Deere 755C Series II have?
The John Deere 755C Series II delivers 132 kW.
How much does the John Deere 755C Series II weigh?
The unladen weight is 21,001 kg.
What engine does the John Deere 755C Series II have?
6 cylinders, 9,996 cm³ displacement.
How fast does the John Deere 755C Series II go?
Top speed is 10.9 km/h.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 19 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
