John Deere 7220 (81 kW)
Built: 2003–2007 · Series: 7020er-Baureihe
More machines from model year 2003
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
John Deere 7020 series – six-cylinder diesels from Waterloo, 2003 to 2006, types 7220 to 7420, 6,788 cc, 81 to 99 kW, torque 448 to 561 Nm
The John Deere 7020 series was built from 2003 to 2006 at the Waterloo plant in Iowa, USA, and covered the mid-range standard tractor class there for the North American market. The register lists the types 7220, 7320 and 7420 here, with the two stronger models additionally listed as a four-wheel-drive version (A). All three models are built around the same six-cylinder diesel engine of 6,788 cc as the sister series built at the same time in Mannheim, but with its own power steps for the American market.
Read on 3 more paragraphs
The register lists 3 versions here with 81 to 99.4 kW from the common six-cylinder of 6,788 cc at 2,100 to 2,300 rpm, torque of 448 to 561 Nm, kerb weights of 5,366 to 5,900 kg, a length of 4,471 mm, a width of 2,438 mm and a height of 2,865 mm.
The 7020 series covered the mid power segment in North American farming and competed with comparable standard tractors from Case IH and New Holland, which served similar arable and livestock holdings in the same period, often paired with a front loader for yard and feeding work.
When buying a used 7020 series model, the key points are operating hours and service history of the six-cylinder engine, condition of clutch and gearbox, and tightness of the hydraulics, plus corrosion on cab and chassis and the condition of the front axle on four-wheel-drive versions; spare parts are well available through regular John Deere parts channels.
Sources: SpecCodex register, model data: John Deere 7020er-Baureihe, John Deere (manufacturer)
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 110 hp (81 kW)correct |
| Rated speed | 2,300 rpmcorrect |
| Torque | 448 Nmcorrect |
| Speed at max. torque | 1,300 rpmcorrect |
| Cylinders | 6correct |
| Displacement | 6,788 cm³correct |
| Bore | 106.5 mmcorrect |
| Stroke | 127 mmcorrect |
| Compression ratio | 17correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 4,471 mmcorrect |
|---|---|
| Width | 2,438 mmcorrect |
| Height | 2,865 mmcorrect |
| Wheelbase | 2,865 mmcorrect |
| Ground clearance | 520 mmcorrect |
| Unladen weight | 5,366 kgcorrect |
Drivetrain and chassis
| Drive | rear- or four-wheel drivecorrect |
|---|---|
| Gearbox | 16V/16R or 24V/24Rcorrect |
| Front tyres | 14.9 R 28 AScorrect |
| Rear tyres | 18.4 R 38 AScorrect |
| Top speed | 30 km/hcorrect |
Working data
| Fuel tank capacity | 207 lcorrect |
|---|
Origin and approval
| Construction | frame constructioncorrect |
|---|
Other data
| Linkage category | Cat IIcorrect |
|---|
Where this model stands
Power-to-weight ratio: 15.1 kW/t (81 kW / 5.4 t)
Power class: Large (100–180 hp)
Stronger than 71% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the John Deere 7220 have?
The John Deere 7220 delivers 110 hp.
How much does the John Deere 7220 weigh?
The unladen weight is 5,366 kg.
What engine does the John Deere 7220 have?
6 cylinders, 6,788 cm³ displacement, Diesel.
How fast does the John Deere 7220 go?
Top speed is 30 km/h.
What are the dimensions of the John Deere 7220?
4,471 mm × 2,438 mm × 2,865 mm.
When was the John Deere 7220 built?
Production years: 2003–2007.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
