John Deere 548G

Series: John Deere Skidder

Source: https://www.agrarheute.com/technik/forsttechnik

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The John Deere Skidder series from John Deere includes the 548G. The engine delivers 122.7 hp (85.8 kW), has 6 cylinders, with a displacement of 5,883 cm³. Rated speed is 2,200 rpm. The unladen weight is 9,861.1 kg. The wheelbase measures 2,923 mm. Ground clearance is 515.1 mm. The tank holds 189.3 litres. The gearbox has 8 forward gears. There are also 4 reverse gears. Maximum torque is reached at 1,400 rpm. The hydraulic tank holds 30.7 litres. Working pressure is 206.8 bar. The cooling system holds 24.6 litres. The oil fill is 18.9 litres. The engine fitted is the 6059T. Tyre size: 28L-26. The John Deere Skidder series covers 25 models. Rated output within it ranges from 122.7 to 202.8 hp; the 548G sits at the bottom of that range with 122.7 hp. Its immediate neighbours are the 540G Series II above it with 128.8 hp. 2153 John Deere models across 96 series are on record. The model is listed under Forestry equipment. 23 verified figures from 1 source are on file.

Technical data

Engine

Engine model6059Tcorrect
Power122.7 hp (85.8 kW)correct
Rated speed2,200 rpmcorrect
Speed at max. torque1,400 rpmcorrect
Cylinders6correct
Displacement5,883 cm³correct
Aspirationturbochargedcorrect
Coolant capacity24.6 lcorrect
Engine oil capacity18.9 lcorrect

Dimensions and weights

Length6,330.7correct
Width3,002.3correct
Wheelbase2,923correct
Ground clearance515.1correct
Unladen weight9,861.1 kgcorrect

Drivetrain and chassis

Gearbox typeplanetarycorrect
Forward gears8correct
Reverse gears4correct
Tyre size28L-26correct

Working data

Hydraulic oil capacity30.7 lcorrect
Hydraulic pressure206.8correct
Fuel tank capacity189.3 lcorrect

Other data

Height3,011.4correct

Where this model stands

Power-to-weight ratio: 8.7 kW/t (86 kW / 9.9 t)

Stronger than 5% of the forestry equipment in the register — out of 111 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the John Deere 548G have?

The John Deere 548G delivers 123 hp.

How much does the John Deere 548G weigh?

The unladen weight is 9,861 kg.

What engine does the John Deere 548G have?

6 cylinders, 5,883 cm³ displacement.

What are the dimensions of the John Deere 548G?

6,331 mm × 3,002 mm.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
