John Deere 540E

Series: John Deere Skidder

Source: https://www.agrarheute.com/technik/forsttechnik

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The John Deere 540E is a model in the John Deere Skidder series. The engine delivers 122.7 hp (85.8 kW), with a displacement of 5,883 cm³. Rated speed is 2,200 rpm. The machine is 2,792 mm wide. The unladen weight is 9,933.7 kg. The wheelbase measures 2,923 mm. Ground clearance is 499.9 mm. The tank holds 157.1 litres. The gearbox has 8 forward gears. There are also 4 reverse gears. Maximum torque is reached at 1,400 rpm. The hydraulic tank holds 30.7 litres. Working pressure is 206.8 bar. The cooling system holds 24.6 litres. The oil fill is 18.9 litres. The engine fitted is the 6059T. Tyre size: 23,1-26 10PR LS2. The John Deere Skidder series covers 25 models. Rated output within it ranges from 122.7 to 202.8 hp; the 540E sits at the bottom of that range with 122.7 hp. Its immediate neighbours are the 540G Series II above it with 128.8 hp. 2153 John Deere models across 96 series are on record. The model is listed under Forestry equipment. 22 verified figures from 1 source are on file.

Technical data

Engine

Engine model6059Tcorrect
Power122.7 hp (85.8 kW)correct
Rated speed2,200 rpmcorrect
Speed at max. torque1,400 rpmcorrect
Displacement5,883 cm³correct
Aspirationturbochargedcorrect
Coolant capacity24.6 lcorrect
Engine oil capacity18.9 lcorrect

Dimensions and weights

Length6,080.8correct
Width2,792correct
Wheelbase2,923correct
Ground clearance499.9correct
Unladen weight9,933.7 kgcorrect

Drivetrain and chassis

Gearbox typedirect-drive power shiftcorrect
Forward gears8correct
Reverse gears4correct
Tyre size23.1-26 10PR LS2correct

Working data

Hydraulic oil capacity30.7 lcorrect
Hydraulic pressure206.8correct
Fuel tank capacity157.1 lcorrect

Other data

Height3,011.4correct

Where this model stands

Power-to-weight ratio: 8.6 kW/t (86 kW / 9.9 t)

Stronger than 5% of the forestry equipment in the register — out of 111 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the John Deere 540E have?

The John Deere 540E delivers 123 hp.

How much does the John Deere 540E weigh?

The unladen weight is 9,934 kg.

What engine does the John Deere 540E have?

5,883 cm³ displacement.

What are the dimensions of the John Deere 540E?

6,081 mm × 2,792 mm.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
