Jinma 754
Series: Other models
The Jinma 754 is a tractor made by Jinma. It is powered by a four-cylinder engine producing 55 kW. Rated power is reached at 2,300 rpm.
It runs with MFWD.
The engine is water-cooled. Within the range, rated power spans from 11.8 to 92 kW; with 55 kW, the 754 sits in the upper third. Directly alongside are the 724 with 54 kW below and the 754A with 56 kW above.
Technical data
Engine
| Engine model | LR4108T79Acorrect |
|---|---|
| Power | 75 hp (55 kW)correct |
| Rated speed | 2,300 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 4.6correct |
| Bore | 108 mmcorrect |
| Stroke | 125 mmcorrect |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Wheelbase | 2,236 mmcorrect |
|---|
Drivetrain and chassis
| Drive | selectable four-wheel drivecorrect |
|---|---|
| Forward gears | 8correct |
| Reverse gears | 2correct |
| Clutch | Dual stagecorrect |
Working data
| PTO speed | 720 or 540/1000correct |
|---|---|
| Linkage category | Cat IIcorrect |
Origin and approval
| Plant | Chinacorrect |
|---|
Frequently asked questions
How much power does the Jinma 754 have?
The Jinma 754 delivers 75 hp.
What engine does the Jinma 754 have?
4 cylinders.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 19 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
