JCB ICX 8FT (208S)

Series: JCB Loader Backhoe

Source: https://www.agrarheute.com/technik/traktoren/2-jcb-radlader-

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The ICX 8FT (208S) from JCB is part of the JCB Loader Backhoe series. The engine delivers 50.7 hp (35 kW), has 4 cylinders, with a displacement of 2,200.8 cm³. Rated speed is 2,800 rpm. The wheelbase measures 1,072.9 mm. Ground clearance is 262.1 mm. The tank holds 45 litres. The gearbox has 1 forward gears. There are also 1 reverse gears. Maximum torque is reached at 2,000 rpm. The pump delivers 46.9 l/min. The hydraulic tank holds 45 litres. Working pressure is 206.8 bar. The cooling system holds 7.9 litres. The electrical system runs on 12 V. The engine fitted is the 404C-22. The JCB Loader Backhoe series covers 36 models. Rated output within it ranges from 20.8 to 101.4 hp; the ICX 8FT (208S) sits in the lower part of that range with 50.7 hp. Its immediate neighbours are the ICXT below it with 49.7 hp and the 2CX Airmaster above it with 56.1 hp. 752 JCB models across 38 series are on record. The model is listed under Wheel loaders. 19 verified figures from 1 source are on file.

Technical data

Engine

Engine model404C-22correct
Power50.7 hp (35 kW)correct
Rated speed2,800 rpmcorrect
Speed at max. torque2,000 rpmcorrect
Cylinders4correct
Displacement2,200.8 cm³correct
Aspirationnaturally aspiratedcorrect
Coolant capacity7.9 lcorrect

Dimensions and weights

Wheelbase1,072.9correct
Ground clearance262.1correct

Drivetrain and chassis

Gearbox typehydrostatic transmissioncorrect
Forward gears1correct
Reverse gears1correct
System voltage12 Vcorrect

Working data

Pump flow46.9 l/mincorrect
Hydraulic oil capacity45 lcorrect
Hydraulic pressure206.8correct
Fuel tank capacity45 lcorrect

Frequently asked questions

How much power does the JCB ICX 8FT (208S) have?

The JCB ICX 8FT (208S) delivers 50.7 hp.

What engine does the JCB ICX 8FT (208S) have?

4 cylinders, 2,201 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
