JCB 426HTM

Series: JCB Integrated Tool Carrier

Source: https://www.agrarheute.com/technik/speziell-fuer-landwirte-j

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The 426HTM from JCB is part of the JCB Integrated Tool Carrier series. The engine delivers 154.1 hp (111.9 kW), with a displacement of 5,901 cm³. Torque is 455 Nm. Rated speed is 2,000 rpm. The tank holds 210.1 litres. The gearbox has 4 forward gears. There are also 3 reverse gears. Maximum torque is reached at 1,600 rpm. The pump delivers 410.3 l/min. The hydraulic tank holds 210.1 litres. The cooling system holds 35.2 litres. The oil fill is 14 litres. The electrical system runs on 24 V. The engine fitted is the BTAA5,9C. Tyre size: 20,5-25 SGG L2. The JCB Integrated Tool Carrier series covers 37 models. Rated output within it ranges from 59.8 to 219 hp; the 426HTM sits in the middle of that range with 154.1 hp. Its immediate neighbours are the 416HT below it with 126.7 hp and the 426HT High Lift above it with 167.3 hp. 752 JCB models across 38 series are on record. The model is listed under Telehandlers. 18 verified figures from 1 source are on file.

Technical data

Engine

Engine modelBTAA5.9Ccorrect
Power154.1 hp (111.9 kW)correct
Rated speed2,000 rpmcorrect
Torque455correct
Speed at max. torque1,600 rpmcorrect
Displacement5,901 cm³correct
Aspirationturbochargedcorrect
Coolant capacity35.2 lcorrect
Engine oil capacity14 lcorrect

Drivetrain and chassis

Gearbox typesmooth shift powershift transmissioncorrect
Forward gears4correct
Reverse gears3correct
Tyre size20.5-25 SGG L2correct
System voltage24 Vcorrect

Working data

Pump flow410.3 l/mincorrect
Hydraulic oil capacity210.1 lcorrect
Fuel tank capacity210.1 lcorrect

Frequently asked questions

How much power does the JCB 426HTM have?

The JCB 426HTM delivers 154 hp.

What engine does the JCB 426HTM have?

5,901 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
