Iveco AS 260 S 48 Y/FS
Built: 2004 · Series: Stralis
More machines from model year 2004
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Iveco Stralis – the long-haul and distribution range 2002–2019: AD rigid chassis and AS/AT tractor unit, Cursor six-cylinder engines, 228 to 419 kW, also as a natural-gas version
The Iveco Stralis was introduced in 2002 as the successor to the EuroTech and EuroStar and built until 2019, when the S-Way took over; Iveco itself was formed in 1975 from the merger of the Fiat, OM, Lancia and Magirus-Deutz commercial-vehicle businesses. The type designation follows a fixed scheme: AD marks the rigid chassis for bodywork, AS and AT the tractor unit, the following number (190, 260, 340, 440 and so on) the weight or power class, the letters P, S and T after the slash the cab height and equipment, and Y and Z the axle configuration. The Stralis is powered by Iveco's own inline six-cylinder Cursor engines; as the Stralis NP there was also a natural-gas-powered variant, likewise recorded in the register.
Read on 3 more paragraphs
The register lists here 146 versions, with six-cylinder engines throughout, displacements of 7,790 to 12,900 cm³, outputs of 228 to 419 kW, unladen weights of 6,960 to 20,275 kg and gross weights of 11,999 to 42,000 kg; for part of the models, lengths of 6,070 to 12,490 mm are also recorded.
For a decade and a half the Stralis was the backbone of Iveco's European range in long-haul and distribution transport and a competitor to the Mercedes-Benz Actros, Scania R/P, Volvo FH and DAF XF; with the natural-gas version Iveco positioned itself early as a pioneer of alternative drives in the heavy-truck segment.
On a used example, operating hours and mileage, the condition of the clutch and automated manual gearbox, the AdBlue and exhaust system, on the NP natural-gas models the condition and inspection dates of the gas tanks, and the brakes and tyres of the drive axle all count; parts and service run through the Iveco dealer network.
Sources: SpecCodex register, model data: Iveco Stralis, Iveco
Technical data
Engine
| Cylinders | 6correct |
|---|---|
| Displacement | 12,882 cm³correct |
Dimensions and weights
| Length | 9,730 mmcorrect |
|---|---|
| Width | 2,500 mmcorrect |
| Wheelbase | 6,390 mmcorrect |
| Unladen weight | 9,850 kgcorrect |
| Gross vehicle weight | 25,700 kgcorrect |
Drivetrain and chassis
| Wheels | 6correct |
|---|
Frequently asked questions
How much does the Iveco AS 260 S 48 Y/FS weigh?
The unladen weight is 9,850 kg.
What is the gross vehicle weight of the Iveco AS 260 S 48 Y/FS?
25,700 kg.
What engine does the Iveco AS 260 S 48 Y/FS have?
6 cylinders, 12,882 cm³ displacement.
What are the dimensions of the Iveco AS 260 S 48 Y/FS?
9,730 mm × 2,500 mm.
When was the Iveco AS 260 S 48 Y/FS built?
Production years: 2004.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 10 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
