Iveco/abk MULTI CAB 1301 EX
Built: 2015-2019 · Series: Other models
More machines from model year 2015
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Iveco chassis with ABK Multi Cab 1301 EX body – dual rear wheels, 3,500 kg gross weight, 7.13 m length and a multi-row crew cab
The model name Multi Cab points to a chassis with a multi-row cab, of the kind used to carry a crew together with tools or materials. The basis is a chassis on six wheels, meaning dual wheels on the rear axle, common on chassis with a cab or platform body from this weight class upward. The operator ABK fitted the specific cab-and-body solution onto this chassis that can be read from the values on record.
Read on 3 more paragraphs
The four-cylinder diesel engine has a displacement of 2,998 cm³. At a gross vehicle weight of 3,500 kg against an unladen weight of 2,649 kg, 851 kg remain for crew, tools and load. The overall length of 7.13 m with a 4.10 m wheelbase leaves a long overhang behind the axle, needed for a combined cab-and-platform body in one unit, while the 2.01 m width is comparatively narrow. The permitted top speed is given as 160 km/h.
At 3,500 kg gross weight the vehicle falls into EU class N1 and can be driven on a category B licence provided crew and load together do not exceed the remaining 851 kg – with a multi-row cab, the weight of the occupants alone already forms a significant part of that reserve. Dual rear wheels increase tip stability under off-centre platform loading compared with single wheels. The narrow width eases work on tight access roads and building sites.
When buying a used multi-row-cab chassis, it is worth checking the seat mounts and belt anchorages of the second row, as they see heavier daily use than a simple driver's cab. With dual wheels, attention should go to matching tyre pressure and tread depth on both tyres per side, since uneven pressure causes one-sided wear. Corrosion under the platform bed and around the dual-wheel arches deserves the same attention as the condition of the load-bed tie-down points.
Sources: SpecCodex-Register: Kennwerte des Modells ABK MULTI CAB 1301 EX
Technical data
Engine
| Cylinders | 4correct |
|---|---|
| Displacement | 2,998 cm³correct |
Dimensions and weights
| Length | 7,130 mmcorrect |
|---|---|
| Width | 2,010 mmcorrect |
| Wheelbase | 4,100 mmcorrect |
| Unladen weight | 2,649 kgcorrect |
| Gross vehicle weight | 3,500 kgcorrect |
Drivetrain and chassis
| Wheels | 6correct |
|---|---|
| Top speed | 160 km/hcorrect |
Frequently asked questions
How much does the Iveco/abk MULTI CAB 1301 EX weigh?
The unladen weight is 2,649 kg.
What is the gross vehicle weight of the Iveco/abk MULTI CAB 1301 EX?
3,500 kg.
What engine does the Iveco/abk MULTI CAB 1301 EX have?
4 cylinders, 2,998 cm³ displacement.
What are the dimensions of the Iveco/abk MULTI CAB 1301 EX?
7,130 mm × 2,010 mm.
When was the Iveco/abk MULTI CAB 1301 EX built?
Production years: 2015-2019.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
