Htf HZP 39
Built: 1995-2009 · Series: HZP
More machines from model year 1995
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
HTF HZP – heavy trailers from the HZP 15 to the HZP 80-030, unladen weights 4,820 to 10,880 kg, permissible gross weights 15,000 to 45,000 kg, lengths up to 14,030 mm, for building-material and heavy-load transport
This page gathers HTF trailers in the HZP range. The type designations combine a two- to three-digit base number with suffixes such as D or B for different equipment variants, from the lighter HZP 15 up to the heavy versions HZP 50-032 and HZP 80-030. Alongside the two-digit base types such as the HZP 32 or HZP 39, the range also carries three-part designations such as the HZP 40-016, with an extra digit after a hyphen.
Read on 3 more paragraphs
The register lists here 20 versions with unladen weights from 4,820 to 10,880 kg, permissible gross weights from 15,000 to 45,000 kg, lengths from 11,260 to 14,030 mm and widths from 2,500 to 2,600 mm.
With gross weights up to 45 tonnes and lengths over 14 metres, the heavier HZP types count among the trailers for heavy-load and building-material haulage, as used in road construction and earthworks for hauling bulk material. Operators run them behind tractor units type-approved for the respective gross weight.
On these heavy-load trailers the axles, braking system and frame need particularly careful checking given the high payloads, as do the body, sides or tipping mechanism and hydraulics on the relevant versions. Tyres and rims should match the permissible axle load, and the air-brake system and registration papers should be checked before purchase. The coupling and jack legs also belong in the check, given the daily strain of heavy-haulage use.
Sources: Kennwerte der Modelle HTF HZP
Technical data
Dimensions and weights
| Length | 14,020 mmcorrect |
|---|---|
| Width | 2,600 mmcorrect |
| Wheelbase | 9,700 mmcorrect |
| Unladen weight | 10,880 kgcorrect |
| Gross vehicle weight | 42,000 kgcorrect |
Drivetrain and chassis
| Top speed | 100 km/hcorrect |
|---|
Frequently asked questions
How much does the Htf HZP 39 weigh?
The unladen weight is 10,880 kg.
What is the gross vehicle weight of the Htf HZP 39?
42,000 kg.
Up to what speed is the Htf HZP 39 approved?
Approved up to 100 km/h.
What are the dimensions of the Htf HZP 39?
14,020 mm × 2,600 mm.
When was the Htf HZP 39 built?
Production years: 1995-2009.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
