Hitachi ZX110M

Series: Hitachi Hydraulic Excavator

Source: https://www.truck1.eu/construction-machinery/crawler-excavat

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

With the ZX110M, Hitachi offers a model from the Hitachi Hydraulic Excavator series. The engine delivers 61.9 kW, has 4 cylinders, with a displacement of 4,429.4 cm³. Torque is 340 Nm. Rated speed is 2,150 rpm. The unladen weight is 12,800 kg. Ground clearance is 597.4 mm. The tank holds 250.2 litres. Maximum torque is reached at 1,600 rpm. The pump delivers 200.2 l/min. The hydraulic tank holds 130.2 litres. Working pressure is 343.4 bar. The cooling system holds 19.3 litres. The oil fill is 15.9 litres. The electrical system runs on 24 V. The engine fitted is the BB-4BG1T. The Hitachi Hydraulic Excavator series covers 158 models. Rated output within it ranges from 42.4 to 481.7 kW; the ZX110M sits at the bottom of that range with 61.9 kW. Its immediate neighbours are the EX130H-5 below it with 60.4 kW and the ZX120 above it with 65.6 kW. Unladen weight within it ranges from 8,143 to 108,000 kg; here the ZX110M sits at the bottom of that range with 12,800 kg. 357 Hitachi models across 24 series are on record.

Hitachi ZX — what the number and letters reveal about weight class

Hitachi codes usually start with ZX, short for the ZAXIS line. The following number places the model in an approximate operating-weight class, letters such as LC, US or W describe the undercarriage and configuration, and a dash number at the end marks the generation.

Read on 4 more paragraphs

LC marks a widened undercarriage for extra stability, US denotes ultra-short-tail models with a compact rear overhang for tight jobsites, and W marks wheeled machines. Current models run as ZAXIS-7, while older stock is still labelled -3, -5 or -6.

Alongside these sits the older EX line, such as the EX700: mechanically simpler than the ZX models, with less electronics, but built rugged for heavy continuous duty.

The collective entry spans small excavators from around 42 kW up to large machines above 480 kW. When buying used, check the hour meter along with the slew ring, boom-and-bucket linkage bushings and any leaks at the hydraulic cylinders.

In short: ZX plus size number plus undercarriage letter plus generation digit make up the full code, as seen on models like ZX120, ZX200 or ZX330.

Sources: Kennwerte der Modelle Hitachi Hydraulic Excavator, ZAXIS-7 Modellcode-Erklaerung, Hitachi Herstellerbroschuere, ZAXIS-7 Grossbagger-Broschuere, Hitachi

Technical data

Engine

Engine modelBB-4BG1Tcorrect
Power61.9 kWcorrect
Rated speed2,150 rpmcorrect
Torque340correct
Speed at max. torque1,600 rpmcorrect
Cylinders4correct
Displacement4,429.4 cm³correct
Aspirationturbochargedcorrect
Coolant capacity19.3 lcorrect
Engine oil capacity15.9 lcorrect

Dimensions and weights

Ground clearance597.4correct
Unladen weight12,800 kgcorrect

Working data

Pump flow200.2 l/mincorrect
Hydraulic oil capacity130.2 lcorrect
Hydraulic pressure343.4 barcorrect
Fuel tank capacity250.2 lcorrect

Other data

Cab height2,950.5correct
System voltage24 Vcorrect

More machines with this engine (BB-4BG1T, 15)

Where this model stands

Power-to-weight ratio: 4.8 kW/t (62 kW / 12.8 t)

Stronger than 19% of the excavators & compaction in the register — out of 1,666 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Hitachi ZX110M have?

The Hitachi ZX110M delivers 61.9 kW.

How much does the Hitachi ZX110M weigh?

The unladen weight is 12,800 kg.

What engine does the Hitachi ZX110M have?

4 cylinders, 4,429 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
