Hermanns CHOSAL SSA
Built: 2006 · Series: Other models
More machines from model year 2006
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Hermanns – other models: trailers outside the named series, SSA and RAL B types, 5,280 to 11,040 kg kerb weight, 33,500 to 39,000 kg gross vehicle weight, class O4
This page collects Hermanns units that the register could not assign to a named series. The CHOSAL SSA, RAL B 42 and SV ST A 2225 designations denote semi-trailers and tandem-axle trailers from the heavy-haulage segment; all versions fall into class O4 (gross vehicle weight above 10 t), well beyond the range of classic car trailers and closer to long-distance haulage and construction logistics.
Read on 3 more paragraphs
The register lists 4 versions here with kerb weights from 5,280 to 11,040 kg and gross vehicle weights from 33,500 to 39,000 kg. Lengths lie between 10,350 and 11,150 mm, widths between 2,500 and 2,550 mm.
Such trailers handle the haulage of bulk goods, machinery and containers in long-distance and construction-site traffic, working behind heavy class N3 tractor units; their design follows the axle-load and coupling requirements of European heavy haulage.
When buying used, check the condition of axles, brake system and air suspension, rust on the chassis, side rails and ramps, the tightness of the hydraulics, plus wear on tyres and brake linings; the inspection history of axle loads and the condition of the fifth-wheel plate give further insight into prior use and possible overloading; cracks in welds at heavily loaded attachment points also deserve a close look, along with the condition of the landing legs.
Sources: SpecCodex register, model data: Hermanns (weitere Modelle)
Technical data
Dimensions and weights
| Length | 10,410 mmcorrect |
|---|---|
| Width | 2,510 mmcorrect |
| Wheelbase | 8,230 mmcorrect |
| Unladen weight | 5,280 kgcorrect |
| Gross vehicle weight | 39,000 kgcorrect |
Drivetrain and chassis
| Top speed | 100 km/hcorrect |
|---|
Frequently asked questions
How much does the Hermanns CHOSAL SSA weigh?
The unladen weight is 5,280 kg.
What is the gross vehicle weight of the Hermanns CHOSAL SSA?
39,000 kg.
Up to what speed is the Hermanns CHOSAL SSA approved?
Approved up to 100 km/h.
What are the dimensions of the Hermanns CHOSAL SSA?
10,410 mm × 2,510 mm.
When was the Hermanns CHOSAL SSA built?
Production years: 2006.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 8 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
