Heinrich Lanz HR 2
Built: 1927–1929 · Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Heinrich Lanz – other models: the collective page of the Mannheim Bulldog tractors with hot-bulb and diesel engines, petrol to crude oil and gas oil, 16.1 to 18.3 kW, 1,190 to 3,950 kg
This page gathers the Heinrich Lanz tractors the register could not assign to a named range – from early types such as the FMA/FMB and HR 2 to the diesel models D 2016, D 5506, D 6007 and D 9506. Heinrich Lanz founded his company in Mannheim, where the Bulldog was built from 1921: a tractor with a horizontal single-cylinder hot-bulb engine that needed no spark plug and was started on petrol before it could be switched to cheaper fuels such as paraffin, crude oil or gas oil. This multi-fuel ability made the Bulldog popular on farms worldwide before Lanz moved to water-cooled diesel engines in the post-war years. In 1956 John Deere took a majority stake in Lanz, and by 1960 the brand name had disappeared from the new-machine range.
Read on 3 more paragraphs
The register lists here 6 versions with 16.1 to 18.3 kW from one- to four-cylinder engines running at 500 to 680 revolutions per minute, unladen weights from 1,190 to 3,950 kg, lengths from 2,745 to 3,650 mm and heights from 1,850 to 2,270 mm; fuels range from petrol to paraffin, crude oil and gas oil.
The Lanz Bulldog counts among the defining designs of German agricultural-machinery history: robust, easy to repair and frugal on fuel, it became the standard farm tractor of the inter-war and post-war years and was also built under licence outside Germany.
On used examples, the condition of the hot bulb and cylinder, the cooling-water circuit and radiator, the clutch and gearbox, and the running gear and tyres all matter; spare parts today run mainly through specialist Bulldog clubs and tractor dealers.
Sources: SpecCodex register, model data: Heinrich Lanz (weitere Modelle), Lanz Bulldog (Wikipedia)
Technical data
Engine
| Fuel | Petroleum, Rohöl, Gasölcorrect |
|---|---|
| Power | 22 hp (16.1 kW)correct |
| Rated speed | 500 rpmcorrect |
| Cylinders | 1correct |
| Bore | 225 mmcorrect |
| Stroke | 260 mmcorrect |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 3,200 mmcorrect |
|---|---|
| Width | 1,650 mmcorrect |
| Height | 2,100 mmcorrect |
| Wheelbase | 1,800 mmcorrect |
| Unladen weight | 2,500 kgcorrect |
Drivetrain and chassis
| Drive | rear-wheel drivecorrect |
|---|---|
| Gearbox | 4V/4Rcorrect |
| Front tyres | 900 x 200correct |
| Rear tyres | 1.150 x 300correct |
| Top speed | 8 km/hcorrect |
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|---|
| Units built | 7,224correct |
Where this model stands
Power-to-weight ratio: 6.4 kW/t (16 kW / 2.5 t)
Power class: Compact (< 40 hp)
Stronger than 9% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Heinrich Lanz HR 2 have?
The Heinrich Lanz HR 2 delivers 22 hp.
How much does the Heinrich Lanz HR 2 weigh?
The unladen weight is 2,500 kg.
What engine does the Heinrich Lanz HR 2 have?
1 cylinders, Petroleum, Rohöl, Gasöl.
How fast does the Heinrich Lanz HR 2 go?
Top speed is 8 km/h.
What are the dimensions of the Heinrich Lanz HR 2?
3,200 mm × 1,650 mm × 2,100 mm.
When was the Heinrich Lanz HR 2 built?
Production years: 1927–1929.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
