Heinrich Lanz A 1315
Built: 1956–1957 · Series: Alldog
More machines from model year 1956
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Heinrich Lanz Alldog A 1315: air-cooled single-cylinder compact diesel tractor, 533 cc, 13 hp/9.5 kW and 1,060 kg weight, from 1956/1957
The Alldog was a small, versatile series from Heinrich Lanz of Mannheim from the second half of the 1950s, standing alongside the manufacturer's large single-cylinder Bulldog field tractors as a compact all-purpose tractor for smaller farms and mixed tasks.
Read on 3 more paragraphs
The A 1315 is powered by an air-cooled single-cylinder diesel engine of 533 cc, producing 13 hp, or 9.5 kW, at 2,800 rpm. At a weight of 1,060 kg, a length of 3,760 mm, a height of 1,665 mm and a width of 1,630 mm, with a wheelbase of 2,234 mm, the machine is a very light small tractor whose top speed of 19.7 km/h even allowed for short road journeys.
An air-cooled single-cylinder with a comparatively high rated speed of 2,800 rpm makes the engine largely immune to frost and does away with a radiator, coolant and water pump as possible sources of wear, though it offers less cooling reserve under sustained full load than a water-cooled unit. Such a light tractor was built for light field work, driving small mounted implements and yard haulage, not for heavy tillage.
When buying an Alldog A 1315, the condition of the cooling fins on the cylinder and of the cooling fan matters, since dirt there leads directly to overheating. Also worth checking are the clutch and gearbox for wear noises and the brakes; parts for such a small and rare Lanz model are now only available from specialist suppliers and salvage stock.
Sources: SpecCodex-Register: Kennwerte des Modells Heinrich Lanz Alldog A 1315
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 13 hp (9.5 kW)correct |
| Rated speed | 2,800 rpmcorrect |
| Cylinders | 1correct |
| Displacement | 533 cm³correct |
| Bore | 85 mmcorrect |
| Stroke | 94 mmcorrect |
| Cooling | air-cooledcorrect |
Dimensions and weights
| Length | 3,760 mmcorrect |
|---|---|
| Width | 1,630 mmcorrect |
| Height | 1,665 mmcorrect |
| Wheelbase | 2,234 mmcorrect |
| Ground clearance | 440 mmcorrect |
| Unladen weight | 1,060 kgcorrect |
Drivetrain and chassis
| Drive | rear-wheel drivecorrect |
|---|---|
| Gearbox | 6V/1Rcorrect |
| Front tyres | 5.50-16correct |
| Rear tyres | 8-24correct |
| Top speed | 19.7 km/hcorrect |
Origin and approval
| Construction | Zweiholm-Bauweisecorrect |
|---|---|
| Units built | 400correct |
Where this model stands
Power-to-weight ratio: 9 kW/t (10 kW / 1.1 t)
Power class: Compact (< 40 hp)
Stronger than 2% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Heinrich Lanz A 1315 have?
The Heinrich Lanz A 1315 delivers 13 hp.
How much does the Heinrich Lanz A 1315 weigh?
The unladen weight is 1,060 kg.
What engine does the Heinrich Lanz A 1315 have?
1 cylinders, 533 cm³ displacement, Diesel.
How fast does the Heinrich Lanz A 1315 go?
Top speed is 19.7 km/h.
What are the dimensions of the Heinrich Lanz A 1315?
3,760 mm × 1,630 mm × 1,665 mm.
When was the Heinrich Lanz A 1315 built?
Production years: 1956–1957.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
