Hbmotor F286TSC-4
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Hbmotor F286TSC-4 – a three-phase industrial motor rated at 22 kilowatts for larger pumps, compressors and conveyor systems in trade and industry
Motors such as the F286TSC-4 described here belong to the class of more powerful three-phase industrial motors that drive larger pumps, compressors, fans and conveyor systems across trades and industry.
Read on 3 more paragraphs
The motor delivers 22 kilowatts, placing it at the upper end of standard drive motors that power larger pumps, screw compressors or belt conveyors. The high starting current of such motors in practice usually calls for star-delta starting or an electronic soft starter.
Under IEC 60072 the frame size sets the shaft centre height and therefore the foot and flange dimensions, so that motors of the same frame size from different makers stay mechanically interchangeable. The squirrel-cage rotor is standard in industrial motors of this kind, while slip-ring rotors are reserved for high starting torque. Protection ratings follow IEC 60529, mounting arrangements IEC 60034-7, for example IM B3, IM B5 or a vertical V1 version. Running it from a frequency inverter raises the demands on winding insulation.
Before buying, check the rating plate and whether voltage and frequency match the intended supply. Turned by hand, the shaft should run freely and quietly; rattling or catching points to worn bearings. The terminal box and cabling deserve a look for corrosion or cracked insulation, which an insulation test clarifies. For inverter duty the winding must be rated accordingly, otherwise premature insulation failure can follow.
Sources: SpecCodex-Register: Kennwerte des Modells F286TSC-4
Technical data
Engine
| Rated output | 22 kWcorrect |
|---|
Dimensions and weights
| Weight | 197 kgcorrect |
|---|
Electrical data
| Rated voltage | 415 Vcorrect |
|---|---|
| Number of poles | 4correct |
| Protection class | IP55correct |
| Frame size | 286TSC-4correct |
| Mounting (IEC 60034-7) | B34correct |
| Efficiency at full load | 92.67 %correct |
| Efficiency at 75 % load | 93.34 %correct |
| Efficiency at half load | 93.04 %correct |
Origin and approval
| Country of manufacture | Chinacorrect |
|---|
Other data
| Standard applied | Greenhouse and Energy Minimum Standards (Three Phase Electric Motors) Determination 2019correct |
|---|---|
| Test method | IEEE 112-B(USA)correct |
Frequently asked questions
How much power does the Hbmotor F286TSC-4 have?
The Hbmotor F286TSC-4 delivers 22 kW.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- Check the ingress rating against the installation site — outdoors or in dust the demands differ.
- Hold the mounting form and dimensions against the existing seat before ordering.
- The pole count sets the speed — when replacing an older unit, compare this first.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
