Hanomag GR 50

Built: 1933 (GR 50/2 1935)–1935 (GR 50/2 1938) · Series: A - Reihe

Source: https://www.technikboerse.com/gebraucht/traktor-357/hanomag-

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Hanomag GR 50 is a model in the A - Reihe series. Production: 1933 (GR 50/2 1935)–1935 (GR 50/2 1938). The engine delivers 50 hp, has 4 cylinders, with a displacement of 5,195 cm³. Rated speed is 1,300 rpm. The machine is 3,270 mm long, 1,660 mm wide and 1,700 mm high. The unladen weight is 3,350 kg. The wheelbase measures 2,180 mm. Top speed is 8 km/h. Transmission: 3V / 1R (GR 50/2 6V, 2R). The engine is water-cooled. Tyres: front 6,00 - 20, rear 12,75 - 28. The fuel is diesel. The PTO runs at 540 rpm. Around ca. 200 units were built. The A - Reihe series covers 3 models. Rated output within it ranges from 38 to 50 hp; the GR 50 sits at the top of that range with 50 hp. Its immediate neighbours are the AR 38 below it with 38 hp. Unladen weight within it ranges from 3,100 to 3,350 kg; here the GR 50 sits at the top of that range with 3,350 kg. 200 Hanomag models across 22 series are on record.

Hanomag A series – the early agricultural tractors from Hanover, AR 38 to GR 50, four-cylinder diesels of 5,195 cc, 38 to 50 hp

The Hanomag A series came from Hannoversche Maschinenbau AG in Hanover, which built agricultural tractors from the 1930s into the 1970s before giving up its farm-machinery division. The types listed here, AR 38, AR 50 and GR 50, carry their output in the name: the number after the abbreviation states the model's power in horsepower, from 38 to 50 hp. All three versions of the series are built around the same four-cylinder diesel engine of 5,195 cc, which reached the series' different power levels depending on tuning.

Read on 3 more paragraphs

The register lists 3 versions here with 38 to 50 hp from the common four-cylinder of 5,195 cc at 1,100 to 1,300 revolutions per minute, kerb weights of 3,100 to 3,350 kg, lengths of 3,270 to 3,420 mm, widths of 1,660 to 1,750 mm and heights of 1,530 to 1,700 mm; one of the versions is additionally recorded as 28 kW.

In West Germany's post-war farming, Hanomag's A-series agricultural tractors competed directly with Deutz, Lanz and Fendt, and their power class covered the middle segment of peasant holdings, for which they handled ploughing, harvest-trailer and transport work.

When buying a used AR or GR model, the key points are the condition of the engine and injection pump, tightness of the cooling system, wear on steering and front axle, and corrosion on mudguards, bonnet and chassis; spare parts for the A series can now only be sourced through dealers specialising in vintage machinery and breakers, since Hanomag stopped farm-machinery production long ago.

Sources: SpecCodex register, model data: Hanomag A-Reihe

Technical data

Engine

Fuel	dieselcorrect
Power	50 hpcorrect
Power	50 hpcorrect
Rated speed	1,300 rpmcorrect
Cylinders	4correct
Displacement	5,195 cm³correct
Cooling	water-cooledcorrect

Dimensions and weights

Length	3,270 mmcorrect
Width	1,660 mmcorrect
Height	1,700 mmcorrect
Wheelbase	2,180 mmcorrect
Unladen weight	3,350 kgcorrect

Drivetrain and chassis

Drive	rear-wheel drivecorrect
Gearbox	3V / 1R (GR 50/2 6V, 2R)correct
Front tyres	6, 00 - 20correct
Rear tyres	12, 75 - 28correct
Top speed	8 km/hcorrect

Origin and approval

Units built	ca. 200correct

Other data

PTO speed	540 rpmcorrect

Where this model stands

Power-to-weight ratio: 11 kW/t (37 kW / 3.4 t)

Power class: Universal (40–100 hp)

Stronger than 34% of the tractors in the register — out of 15,663 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Hanomag GR 50 have?

The Hanomag GR 50 delivers 50 hp.

How much does the Hanomag GR 50 weigh?

The unladen weight is 3,350 kg.

What engine does the Hanomag GR 50 have?

4 cylinders, 5,195 cm³ displacement, Diesel.

How fast does the Hanomag GR 50 go?

Top speed is 8 km/h.

What are the dimensions of the Hanomag GR 50?

3,270 mm × 1,660 mm × 1,700 mm.

When was the Hanomag GR 50 built?

Production years: 1933 (GR 50/2 1935)–1935 (GR 50/2 1938).

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
Shift the gearbox cold and warm — jumps only show up at temperature.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
