Start › Excavators & compaction › Halla › HE360LCH

Halla HE360LCH

Series: Halla Hydraulic Excavator

Source: https://www.truck1.eu/agricultural-machinery/nnp

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The HE360LCH from Halla is part of the Halla Hydraulic Excavator series. The engine delivers 253 hp (186.1 kW), has 6 cylinders, with a displacement of 9,996.1 cm³. Torque is 1,176.9 Nm. Rated speed is 1,800 rpm. The unladen weight is 35,499.5 kg. Ground clearance is 566.9 mm. The tank holds 530.3 litres. Maximum torque is reached at 1,300 rpm. The pump delivers 590.1 l/min. The hydraulic tank holds 415.3 litres. Working pressure is 343.2 bar. The cooling system holds 47.3 litres. The oil fill is 30.3 litres. The electrical system runs on 24 V. The engine fitted is the LTA 10-C. The Halla Hydraulic Excavator series covers 3 models. Rated output within it ranges from 112 to 186.1 kW; the HE360LCH sits at the top of that range with 186.1 kW. Its immediate neighbours are the HE280LC below it with 132.1 kW. 7 Halla models across 4 series are on record. The model is listed under Excavators & compaction. 19 verified figures from 1 source are on file.

Technical data

Engine

Engine model	LTA 10-Ccorrect
Power	253 hp (186.1 kW)correct
Rated speed	1,800 rpmcorrect
Torque	1,176.9correct
Speed at max. torque	1,300 rpmcorrect
Cylinders	6correct
Displacement	9,996.1 cm³correct
Aspiration	turbochargedcorrect
Coolant capacity	47.3 lcorrect
Engine oil capacity	30.3 lcorrect

Dimensions and weights

Ground clearance	566.9correct
Unladen weight	35,499.5 kgcorrect

Drivetrain and chassis

System voltage	24 Vcorrect

Working data

Pump flow	590.1 l/mincorrect
Hydraulic oil capacity	415.3 lcorrect
Hydraulic pressure	343.2 barcorrect
Fuel tank capacity	530.3 lcorrect

Other data

Height	2,459.7correct

Where this model stands

Power-to-weight ratio: 5.2 kW/t (186 kW / 35.5 t)

Stronger than 79% of the excavators & compaction in the register — out of 1,666 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Halla HE360LCH have?

The Halla HE360LCH delivers 253 hp.

How much does the Halla HE360LCH weigh?

The unladen weight is 35,500 kg.

What engine does the Halla HE360LCH have?

6 cylinders, 9,996 cm³ displacement.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
