Halla HE280LC

Series: Halla Hydraulic Excavator

Source: https://www.truck1.eu/agricultural-machinery/nnp

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

With the HE280LC, Halla offers a model from the Halla Hydraulic Excavator series. The engine delivers 132.1 kW, has 6 cylinders, with a displacement of 8,275.5 cm³. Torque is 796 Nm. The unladen weight is 28,200 kg. Ground clearance is 499.9 mm. The tank holds 530.3 litres. Maximum torque is reached at 1,500 rpm. The pump delivers 520.1 l/min. The hydraulic tank holds 380.1 litres. Working pressure is 342.7 bar. The cooling system holds 28 litres. The oil fill is 22.7 litres. The electrical system runs on 24 V. The engine fitted is the 6CT8,3-C. The Halla Hydraulic Excavator series covers 3 models. Rated output within it ranges from 112 to 186.1 kW; the HE280LC sits in the lower part of that range with 132.1 kW. Its immediate neighbours are the HE220LC below it with 112 kW and the HE360LCH above it with 186.1 kW. 7 Halla models across 4 series are on record. The model is listed under Excavators & compaction. 17 verified figures from 1 source are on file.

Technical data

Engine

Engine model	6CT8.3-Ccorrect
Power	132.1 kWcorrect
Torque	796correct
Speed at max. torque	1,500 rpmcorrect
Cylinders	6correct
Displacement	8,275.5 cm³correct
Aspiration	turbochargedcorrect
Coolant capacity	28 lcorrect
Engine oil capacity	22.7 lcorrect

Dimensions and weights

Ground clearance	499.9correct
Unladen weight	28,200 kgcorrect

Drivetrain and chassis

System voltage	24 Vcorrect

Working data

Pump flow	520.1 l/mincorrect
Hydraulic oil capacity	380.1 lcorrect
Hydraulic pressure	342.7 barcorrect
Fuel tank capacity	530.3 lcorrect

Other data

Height	3,051correct

Where this model stands

Power-to-weight ratio: 4.7 kW/t (132 kW / 28.2 t)

Stronger than 65% of the excavators & compaction in the register — out of 1,666 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Halla HE280LC have?

The Halla HE280LC delivers 132 kW.

How much does the Halla HE280LC weigh?

The unladen weight is 28,200 kg.

What engine does the Halla HE280LC have?

6 cylinders, 8,276 cm³ displacement.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
