Hako Hans Koch & Sohn HAKOrecord
Built: 1959 · Series: HAKOrecord
More machines from model year 1959
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Hako HAKOrecord: air-cooled single-cylinder two-stroke with belt drive, Variomatic adjustment, 148 cc, 6 hp and a weight of only 135 kg, built in 1959
Hako Hans Koch & Sohn was the earlier company name of the manufacturer known today as Hako, based in Bad Oldesloe in Schleswig-Holstein. The HAKOrecord, from the series of the same name, was built in 1959.
Read on 3 more paragraphs
The HAKOrecord is powered by an air-cooled single-cylinder engine of 148 cc, producing 6 hp at 4,500 rpm and running on a two-stroke fuel mix of 1:25, previously 1:20. Power is transmitted through a belt drive, with speed changed through a manual gearbox combined with a Variomatic adjustment. At a weight of 135 kg, a length of 1,850 mm, a height of 1,250 mm and a width of 850 mm, the machine reaches a top speed of 18 km/h, fitted with 6.00-16, or alternatively 4.00-12, front tyres.
Such a light single-cylinder two-stroke with belt drive and Variomatic adjustment is among the simplest and lightest drive solutions in small-tractor building of the 1950s: the Variomatic adjustment allows stepless matching of travel speed to drawbar pull, similar to a V-belt transmission, without needing the mechanics of a full gearbox with several fixed ratios. A machine of this weight and output was intended for the smallest gardens, tree nurseries or yard work, not for field work on larger areas.
When buying a HAKOrecord secondhand, the condition of the drive belt and the Variomatic adjustment matters most, since wear here directly affects power transmission. Also worth checking are the cooling fins of the air-cooled engine, the carburettor setting for the two-stroke mix, and the tyres in their stated special sizes; spare parts for such an old and light small machine are now only available through specialist collectors and suppliers.
Sources: SpecCodex-Register: Kennwerte des Modells Hako HAKOrecord
Technical data
Engine
| Fuel | Mischung 1:25, früher: 1:20correct |
|---|---|
| Power | 6 hpcorrect |
| Rated speed | 4,500 rpmcorrect |
| Cylinders | 1correct |
| Displacement | 148 cm³correct |
| Cooling | air-cooledcorrect |
Dimensions and weights
| Length | 1,850 mmcorrect |
|---|---|
| Width | 850 mmcorrect |
| Height | 1,250 mmcorrect |
| Unladen weight | 135 kgcorrect |
Drivetrain and chassis
| Drive | Riemencorrect |
|---|---|
| Gearbox | manual gearbox gearbox and Variomaticcorrect |
| Front tyres | 6.00-16 od. 4.00-12correct |
| Top speed | 18 km/hcorrect |
Where this model stands
Power-to-weight ratio: 32.7 kW/t (4 kW / 0.1 t)
Power class: Compact (< 40 hp)
Stronger than 0% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Hako Hans Koch & Sohn HAKOrecord have?
The Hako Hans Koch & Sohn HAKOrecord delivers 6 hp.
How much does the Hako Hans Koch & Sohn HAKOrecord weigh?
The unladen weight is 135 kg.
What engine does the Hako Hans Koch & Sohn HAKOrecord have?
1 cylinders, 148 cm³ displacement, Mischung 1:25, früher: 1:20.
How fast does the Hako Hans Koch & Sohn HAKOrecord go?
Top speed is 18 km/h.
What are the dimensions of the Hako Hans Koch & Sohn HAKOrecord?
1,850 mm × 850 mm × 1,250 mm.
When was the Hako Hans Koch & Sohn HAKOrecord built?
Production years: 1959.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
