Gutbrod 4300 D
Built: from 1990 · Series: 8924450
More machines from model year 1990
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Gutbrod 4300 D: three-cylinder diesel tractor, 1,425 cc, 21 kW, 1,120 kg weight, 1,300 mm width and a top speed of 20 km/h, built from 1990
Gutbrod was a German maker that, after ending car production, switched to garden and compact tractors and, into the 1990s, expanded its range with powered equipment for commercial horticulture; the 4300 D belonged to the later, larger models in this range and was built from 1990.
Read on 3 more paragraphs
The 4300 D is powered by a three-cylinder diesel engine of 1,425 cc, producing 29 hp, or 21 kW, at 2,450 rpm. At a weight of 1,120 kg, a length of 2,900 mm and a width of 1,300 mm, the machine reaches a top speed of 20 km/h.
A three-cylinder diesel engine of nearly 1.5 litres at a weight of just over a tonne marks out a tractor at the upper end of the compact class, suited to tillage with medium implements, mowing on larger areas and running a power take-off at the standard speeds of 540 or 1,000 rpm. This gives the 4300 D a broader range of use than the smaller Gutbrod models, bringing it close to the power class of light general-purpose tractors from other makers.
When buying a Gutbrod 4300 D secondhand, the condition of the diesel engine's injection pump and injectors, and the clutch and gearbox for wear, matter most. Also worth checking are the frame and axles for rust, the brakes, and the power-take-off coupling for mounted implements; spare parts for this later Gutbrod model are available through specialist suppliers, though with longer lead times than for the more common smaller series.
Sources: SpecCodex-Register: Kennwerte des Modells Gutbrod 4300 D
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 29 hp (21 kW)correct |
| Rated speed | 2,450 rpmcorrect |
| Cylinders | 3correct |
| Displacement | 1,425 cm³correct |
Dimensions and weights
| Length | 2,900 mmcorrect |
|---|---|
| Width | 1,300 mmcorrect |
| Height | 2,100 mmcorrect |
| Unladen weight | 1,120 kgcorrect |
Drivetrain and chassis
| Gearbox | 12/4-manual gearbox gearboxcorrect |
|---|---|
| Forward gears | 12correct |
| Reverse gears | 4correct |
| Top speed | 20 km/hcorrect |
Working data
| Fuel tank capacity | 22 lcorrect |
|---|
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|
Other data
| PTO speed | 540/1000 rpmcorrect |
|---|
Where this model stands
Power-to-weight ratio: 18.7 kW/t (21 kW / 1.1 t)
Power class: Compact (< 40 hp)
Stronger than 16% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Gutbrod 4300 D have?
The Gutbrod 4300 D delivers 29 hp.
How much does the Gutbrod 4300 D weigh?
The unladen weight is 1,120 kg.
What engine does the Gutbrod 4300 D have?
3 cylinders, 1,425 cm³ displacement, Diesel.
How fast does the Gutbrod 4300 D go?
Top speed is 20 km/h.
What are the dimensions of the Gutbrod 4300 D?
2,900 mm × 1,300 mm × 2,100 mm.
When was the Gutbrod 4300 D built?
Production years: 1990–?.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
