Gulikers LM3500
Built: 2008 · Series: Other models
More machines from model year 2008
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Gulikers LM3500 – EU category O2 trailer: 3,500 kg gross weight, 620 kg unladen weight, 7,450 mm length, 2,420 mm width, overrun brake
With a gross weight of 3,500 kg, the LM3500 falls into EU trailer category O2, the group of trailers between 750 kg and 3,500 kg.
Read on 3 more paragraphs
Unladen weight is 620 kg, giving a payload of 2,880 kg – more than four fifths of the gross weight is available for cargo. Length stands at 7,450 mm and width at 2,420 mm. The four wheels form a tandem axle set with only 800 mm between the axles within the group, a figure reflecting the tight spacing within the axle group rather than the wheelbase of the trailer as a whole.
Trailers of this class usually run on an overrun brake: as the tow vehicle brakes, the drawbar compresses and mechanically applies the trailer's brakes, with no separate brake line to the tow vehicle. The very low unladen weight over a length of more than 7 metres points to a light frame or platform build, of the kind used to carry boats, vehicles, or bulky but light goods.
On a used example, what counts is the condition of the overrun mechanism and its damper, the working mechanical brake linkage, and rust at the frame and the closely spaced tandem axle group. On a build this light, it is also worth checking the frame for distortion and cracking, since thin-walled sections respond more sensitively to overloading than heavier structures. A current inspection record is a further plus point.
Sources: SpecCodex-Register: Kennwerte des Modells Gulikers LM3500
Technical data
Dimensions and weights
| Length | 7,450 mmcorrect |
|---|---|
| Width | 2,420 mmcorrect |
| Wheelbase | 800 mmcorrect |
| Unladen weight | 620 kgcorrect |
| Gross vehicle weight | 3,500 kgcorrect |
Drivetrain and chassis
| Wheels | 4correct |
|---|---|
| Top speed | 100 km/hcorrect |
Frequently asked questions
How much does the Gulikers LM3500 weigh?
The unladen weight is 620 kg.
What is the gross vehicle weight of the Gulikers LM3500?
3,500 kg.
Up to what speed is the Gulikers LM3500 approved?
Approved up to 100 km/h.
What are the dimensions of the Gulikers LM3500?
7,450 mm × 2,420 mm.
When was the Gulikers LM3500 built?
Production years: 2008.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
