Grove T60 4WD
Series: Grove Boom Lift
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Grove boom lifts A, AMZ and T – the Manlift years from Shady Grove: A for articulating, T for telescopic, AMZ for the Z layout, the number as platform height in feet, 15 to 82 kW
Grove is a crane name today, but from the 1970s to the early 2000s Grove Manlift in Shady Grove, Pennsylvania, also built aerial work platforms – a division Manitowoc gave up after taking over Grove in 2002, which is why the lifts in the register are the last generation of that line. The type logic: A stands for Articulating, the articulated telescopic lift, T for Telescopic, the straight boom with direct reach, AMZ for the articulating lifts in Z layout with double parallelogram; the number gives the platform height in feet – A45J about 45 ft, T60 60 ft, T110 110 ft, A125J 125 ft, i.e. a good 38 m – J marks the jib, E and NE electric drive and the narrow electric layout, 2WD and 4WD or AWD the drive, XT an upgrade level.
Read on 3 more paragraphs
The register lists 25 versions with 14.9 to 82 kW – Ford LRG-425 as petrol and LPG engine, Kubota and Deutz as diesels – service weights from 4,491 to 21,727 kg, lengths up to 8,669 mm and widths from 1,210 to 2,600 mm.
The Grove lifts were the third force of the American market alongside JLG and Genie; their design did not live on after 2002, but the machines still run in rental fleets today because hydraulics and steelwork were built to crane standards.
On used lifts, operating hours, play in boom and slew-ring bearings, the condition of cylinders and hoses, the function of tilt and load sensors, parts supply, which now runs only through specialists and engine makers, and a valid periodic inspection are what count.
Sources: SpecCodex register, model data: Grove Auslegerbühnen, Grove (Manitowoc, Markeninhaber)
Technical data
Engine
| Engine model | LRG4.25correct |
|---|---|
| Power | 60.8 hp (44.7 kW)correct |
Dimensions and weights
| Length | 8,600 mmcorrect |
|---|---|
| Width | 2,590.8 mmcorrect |
| Wheelbase | 2,740.2 mmcorrect |
| Ground clearance | 304.8 mmcorrect |
| Unladen weight | 10,841 kgcorrect |
Drivetrain and chassis
| Tyre size | 15x19.5correct |
|---|---|
| Top speed | 6 km/hcorrect |
Working data
| Hydraulic oil capacity | 136.7 lcorrect |
|---|---|
| Fuel tank capacity | 95 lcorrect |
More machines with this engine (LRG4.25, 7)
Where this model stands
Power-to-weight ratio: 4.1 kW/t (45 kW / 10.8 t)
Stronger than 59% of the aerial work platforms in the register — out of 205 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Grove T60 4WD have?
The Grove T60 4WD delivers 60.8 hp.
How much does the Grove T60 4WD weigh?
The unladen weight is 10,841 kg.
How fast does the Grove T60 4WD go?
Top speed is 6 km/h.
What are the dimensions of the Grove T60 4WD?
8,600 mm × 2,591 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
