Grove RT9130E-2

Series: Grove Rough Terrain Crane

Source: https://www.technikboerse.com/en/gebraucht/working-platform-

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Grove Rough Terrain Crane series from Grove includes the RT9130E-2. The engine delivers 304.6 hp (224 kW), with a displacement of 8,300 cm³. Torque is 1,356.1 Nm. Rated speed is 2,200 rpm. The unladen weight is 78,940.5 kg. The tank holds 379.3 litres. The gearbox has 6 forward gears. There are also 3 reverse gears. Maximum torque is reached at 1,600 rpm. The hydraulic tank holds 1,230.3 litres. The electrical system runs on 12 V. The engine fitted is the QSC8,3L diesel. Tyre size: 33,25x29-38bias. The Grove Rough Terrain Crane series covers 81 models. Rated output within it ranges from 106.1 to 608.3 hp; the RT9130E-2 sits in the lower part of that range with 304.6 hp. Its immediate neighbours are the RT990 below it with 284.2 hp and the RT9150E above it with 325 hp. 338 Grove models across 8 series are on record. The model is listed under Cranes & access platforms. 15 verified figures from 1 source are on file.

Technical data

Engine

Engine modelQSC8.3L dieselcorrect
Power304.6 hp (224 kW)correct
Rated speed2,200 rpmcorrect
Torque1,356.1correct
Speed at max. torque1,600 rpmcorrect
Displacement8,300 cm³correct

Dimensions and weights

Unladen weight78,940.5 kgcorrect

Drivetrain and chassis

Gearbox typefull powershift transmissioncorrect
Forward gears6correct
Reverse gears3correct
Tyre size33.25x29-38biascorrect
System voltage12 Vcorrect

Working data

Hydraulic oil capacity1,230.3 lcorrect
Fuel tank capacity379.3 lcorrect

Where this model stands

Power-to-weight ratio: 2.8 kW/t (224 kW / 78.9 t)

Stronger than 59% of the mobile & rough terrain cranes in the register — out of 591 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Grove RT9130E-2 have?

The Grove RT9130E-2 delivers 305 hp.

How much does the Grove RT9130E-2 weigh?

The unladen weight is 78,940 kg.

What engine does the Grove RT9130E-2 have?

8,300 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 15 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
