Grove RT1650

Series: Grove Rough Terrain Crane

Source: https://www.truck1.eu/construction-machinery/mobile-cranes/g

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Grove RT1650 is a model in the Grove Rough Terrain Crane series. The engine delivers 608.3 hp (447.4 kW), has 6 cylinders. Torque is 1,875.1 Nm. Rated speed is 2,100 rpm. The unladen weight is 106,637.8 kg. The wheelbase measures 550.4 mm. Ground clearance is 566.9 mm. The tank holds 946.4 litres. The gearbox has 4 forward gears. There are also 4 reverse gears. Maximum torque is reached at 1,600 rpm. The pump delivers 1,343.8 l/min. The hydraulic tank holds 2,082.4 litres. The electrical system runs on 24 V. The engine fitted is the KTA-1150-C. Tyre size: 33,25x29-32PR. The Grove Rough Terrain Crane series covers 81 models. Rated output within it ranges from 106.1 to 608.3 hp; the RT1650 sits at the top of that range with 608.3 hp. Its immediate neighbours are the RT9150E below it with 325 hp. 338 Grove models across 8 series are on record. The model is listed under Cranes & access platforms. 19 verified figures from 1 source are on file.

Technical data

Engine

Engine modelKTA-1150-Ccorrect
Power608.3 hp (447.4 kW)correct
Rated speed2,100 rpmcorrect
Torque1,875.1correct
Speed at max. torque1,600 rpmcorrect
Cylinders6correct
Aspirationturbochargedcorrect

Dimensions and weights

Wheelbase550.4correct
Ground clearance566.9correct
Unladen weight106,637.8 kgcorrect

Drivetrain and chassis

Gearbox typetwin powershift transmissioncorrect
Forward gears4correct
Reverse gears4correct
Tyre size33.25x29-32PRcorrect
System voltage24 Vcorrect

Working data

Pump flow1,343.8 l/mincorrect
Hydraulic oil capacity2,082.4 lcorrect
Fuel tank capacity946.4 lcorrect

Where this model stands

Power-to-weight ratio: 4.2 kW/t (447 kW / 106.6 t)

Stronger than 98% of the mobile & rough terrain cranes in the register — out of 591 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Grove RT1650 have?

The Grove RT1650 delivers 608 hp.

How much does the Grove RT1650 weigh?

The unladen weight is 106,638 kg.

What engine does the Grove RT1650 have?

6 cylinders.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
