Grove RT9150E

Series: Grove Rough Terrain Crane

Source: https://www.technikboerse.com/en/gebraucht/working-platform-

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Grove RT9150E is a model in the Grove Rough Terrain Crane series. The engine delivers 325 hp (239.1 kW), with a displacement of 8,300 cm³. Torque is 1,383.1 Nm. Rated speed is 2,200 rpm. The unladen weight is 78,940.5 kg. The wheelbase measures 4,940 mm. The tank holds 379.3 litres. The gearbox has 6 forward gears. There are also 3 reverse gears. Maximum torque is reached at 1,600 rpm. The hydraulic tank holds 1,230.3 litres. The electrical system runs on 12 V. The engine fitted is the QSC8,3L diesel. Tyre size: 33,25x29-38bias. The Grove Rough Terrain Crane series covers 81 models. Rated output within it ranges from 106.1 to 608.3 hp; the RT9150E sits in the middle of that range with 325 hp. Its immediate neighbours are the RT9130E below it with 304.6 hp and the RT1650 above it with 608.3 hp. 338 Grove models across 8 series are on record. The model is listed under Cranes & access platforms. 16 verified figures from 1 source are on file.

Technical data

Engine

Engine modelQSC8.3L dieselcorrect
Power325 hp (239.1 kW)correct
Rated speed2,200 rpmcorrect
Torque1,383.1correct
Speed at max. torque1,600 rpmcorrect
Displacement8,300 cm³correct

Dimensions and weights

Wheelbase4,940correct
Unladen weight78,940.5 kgcorrect

Drivetrain and chassis

Gearbox typefull powershift transmissioncorrect
Forward gears6correct
Reverse gears3correct
Tyre size33.25x29-38biascorrect
System voltage12 Vcorrect

Working data

Hydraulic oil capacity1,230.3 lcorrect
Fuel tank capacity379.3 lcorrect

Where this model stands

Power-to-weight ratio: 3 kW/t (239 kW / 78.9 t)

Stronger than 63% of the mobile & rough terrain cranes in the register — out of 591 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Grove RT9150E have?

The Grove RT9150E delivers 325 hp.

How much does the Grove RT9150E weigh?

The unladen weight is 78,940 kg.

What engine does the Grove RT9150E have?

8,300 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
