Grove AMZ46NE – specifications
Series: Grove Boom Lift
Build year not documented · Data origin: Directory data · sources
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The AMZ46NE is a Z-boom articulated telescopic boom lift with a double parallelogram from the Grove Boom Lift series. This model belongs to the final generation of this line, which Grove Manlift produced until the early 2000s before Manitowoc discontinued the division following its acquisition. The designation AMZ identifies the specific articulation mechanism, while the number 46 indicates the platform height in feet. The suffix NE denotes the narrow electric configuration with electric drive.
With an empty weight of 5,942 kg and a width of 1,500 mm, the machine is designed for use in confined indoor spaces. The maximum travel speed of 4.8 km/h is intended solely for maneuvering, as the lifts primarily operate in stationary mode. The platform provides space for operators with a length of 1,220.2 mm and a width of 760.2 mm, with a load capacity of 103 kg. The drive system uses two batteries with a total capacity of 370 Ah at a system voltage of 48 V, enabling emission-free operation. The 7x15 NHS 12PR air-filled tires dampen vibrations on uneven warehouse floors.
Within the series, the AMZ46NE ranks 18th out of 25 recorded models in terms of empty weight. The next smaller model is the AMZ46E at 5,262 kg, while the next larger variant, the T40 AWD, weighs 6,214 kg. In this weight class, the machine is virtually identical to the T40 2WD, A40NE, and A45EJ types. The total range of empty weights in this series spans from 4,491 kg to 21,727 kg, placing the AMZ46NE in the lower to mid-range segment of this spectrum.
Grove boom lifts A, AMZ and T – the Manlift years from Shady Grove: A for articulating, T for telescopic, AMZ for the Z layout, the number as platform height in feet, 15 to 82 kW
Grove is a crane name today, but from the 1970s to the early 2000s Grove Manlift in Shady Grove, Pennsylvania, also built aerial work platforms – a division Manitowoc gave up after taking over Grove in 2002, which is why the lifts in the register are the last generation of that line. The type logic: A stands for Articulating, the articulated telescopic lift, T for Telescopic, the straight boom with direct reach, AMZ for the articulating lifts in Z layout with double parallelogram; the number gives the platform height in feet – A45J about 45 ft, T60 60 ft, T110 110 ft, A125J 125 ft, i.e. a good 38 m – J marks the jib, E and NE electric drive and the narrow electric layout, 2WD and 4WD or AWD the drive, XT an upgrade level.
Read on 3 more paragraphs
The register lists 25 versions with 14.9 to 82 kW – Ford LRG-425 as petrol and LPG engine, Kubota and Deutz as diesels – service weights from 4,491 to 21,727 kg, lengths up to 8,669 mm and widths from 1,210 to 2,600 mm.
The Grove lifts were the third force of the American market alongside JLG and Genie; their design did not live on after 2002, but the machines still run in rental fleets today because hydraulics and steelwork were built to crane standards.
On used lifts, operating hours, play in boom and slew-ring bearings, the condition of cylinders and hoses, the function of tilt and load sensors, parts supply, which now runs only through specialists and engine makers, and a valid periodic inspection are what count.
Sources: SpecCodex register, model data: Grove Auslegerbühnen, Grove (Manitowoc, Markeninhaber)
Technical data
Dimensions and weights
| Length | 5,690 mmcorrect |
|---|---|
| Width | 1,500 mmcorrect |
| Ground clearance | 150.1 mmcorrect |
| Unladen weight | 5,942 kgcorrect |
| Platform length | 1,220.2 mmcorrect |
| Platform width | 760.2 mmcorrect |
Drivetrain and chassis
| Tyre size | 7x15 NHS 12PRcorrect |
|---|---|
| Tyre type | aircorrect |
| Top speed | 4.8 km/hcorrect |
Working data
| Hydraulic oil capacity | 18.9 lcorrect |
|---|---|
| Platform capacity | 103 kgcorrect |
Electrical data
| Battery capacity | 370 Ahcorrect |
|---|---|
| Number of batteries | 2correct |
Other data
| System voltage | 48 Vcorrect |
|---|
Frequently asked questions
How much does the Grove AMZ46NE weigh?
The unladen weight is 5,942 kg.
What are the dimensions of the Grove AMZ46NE?
5,690 mm × 1,500 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
