Gofa DB 30/1
Built: 1993-1993 · Series: DB
More machines from model year 1993
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Gofa DB – silo and tank semi-trailers from Goch: 19 models, unladen weight 5,480 to 9,360 kg, gross vehicle weight 20 to 45.5 tonnes
Gofa Gocher Fahrzeugbau, based in Goch on the Lower Rhine, builds silo, tank and gas vehicles for transporting cryogenic and non-cryogenic media; since 2011 the company has belonged to the US Chart Industries group. The DB range covers semi-trailers for bulk goods, whose designations such as DB 25, DB 30/1 or DB 40000/4 refer to loading volume and axle configuration.
Read on 3 more paragraphs
The register lists 19 versions of the DB range with unladen weights from 5,480 to 9,360 kg and gross vehicle weights from 20,000 to 45,500 kg. Four of the models also carry lengths from 10,200 to 12,000 mm, while widths run from 2,450 to 2,500 mm.
With 19 listed variants, DB is the most finely staged range in the register among the silo and tank semi-trailers covered here, spanning a wide field from the lighter 20-tonne semi-trailer to the 45.5-tonne version. With this spread, Gofa positions itself between the classic bulk-goods silos for dry material and the tank and gas vehicles of parent company Chart Industries.
On a used silo or gas vehicle of this type, the tightness of the vessel, valves and lines, the condition of the insulation, the compressed-air or compressor system, and corrosion on the frame and suspension all matter. The axles, braking system and kingpin belong in the check, and for pressure and gas vessels the date of the next recurring vessel inspection as well.
Sources: Kennwerte der Modelle Gofa DB, Gofa (Chart Industries, Hersteller)
Technical data
Dimensions and weights
| Width | 2,500 mmcorrect |
|---|---|
| Wheelbase | 791 mmcorrect |
| Unladen weight | 8,400 kgcorrect |
| Gross vehicle weight | 38,000 kgcorrect |
Drivetrain and chassis
| Top speed | 100 km/hcorrect |
|---|
Frequently asked questions
How much does the Gofa DB 30/1 weigh?
The unladen weight is 8,400 kg.
What is the gross vehicle weight of the Gofa DB 30/1?
38,000 kg.
Up to what speed is the Gofa DB 30/1 approved?
Approved up to 100 km/h.
When was the Gofa DB 30/1 built?
Production years: 1993.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 7 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
