Goegl MHT 1700
Built: 2021 · Series: Other models
More machines from model year 2021
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Goegl MHT 1700 – EU category O4 trailer: 17,000 kg gross weight, 5,760 kg unladen weight, 8,500 mm length, 6,150 mm wheelbase
With a gross weight of 17,000 kg, the MHT 1700 falls into EU trailer category O4, the group of heavy trailers above 10 tonnes used in commercial haulage.
Read on 3 more paragraphs
Unladen weight is 5,760 kg, giving a payload of 11,240 kg – well over half the gross weight is available for cargo. Length stands at 8,500 mm, width at 2,350 mm and wheelbase at 6,150 mm: the axle group sits far back on the long body, typical of a trailer built along centre-axle lines.
Air brakes are required at this weight; a mechanical overrun brake is no longer permitted above roughly 3.5 tonnes gross weight. The far-back wheelbase eases the load on the drawbar and the nose weight on the tow vehicle's coupling, but calls for more practice when reversing and manoeuvring than a closely coupled trailer. The tow vehicle would be a lorry requiring category C or CE.
On a used trailer of this kind, what counts is the condition of the brake system and linings, the tightness of the air lines, and rust at the frame, drawbar and axle mounts. With the wheelbase set this far back, it is also worth checking the drawbar for distortion, since it carries the full towing forces over a large part of the vehicle's length. Remaining tyre tread depth and the working lighting also belong on the checklist, and uneven wear across the axle group often points to a bent drawbar.
Sources: SpecCodex-Register: Kennwerte des Modells Goegl MHT 1700
Technical data
Dimensions and weights
| Length | 8,500 mmcorrect |
|---|---|
| Width | 2,350 mmcorrect |
| Wheelbase | 6,150 mmcorrect |
| Unladen weight | 5,760 kgcorrect |
| Gross vehicle weight | 17,000 kgcorrect |
Drivetrain and chassis
| Wheels | 4correct |
|---|---|
| Top speed | 100 km/hcorrect |
Frequently asked questions
How much does the Goegl MHT 1700 weigh?
The unladen weight is 5,760 kg.
What is the gross vehicle weight of the Goegl MHT 1700?
17,000 kg.
Up to what speed is the Goegl MHT 1700 approved?
Approved up to 100 km/h.
What are the dimensions of the Goegl MHT 1700?
8,500 mm × 2,350 mm.
When was the Goegl MHT 1700 built?
Production years: 2021.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
