G Lauxmann 22 PS
Built: 1950 · Series: Other models
More machines from model year 1950
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
G. Lauxmann 22 PS: water-cooled two-cylinder diesel tractor with rear-wheel drive, 2,360 cc and 16.2 kW, of which only 4 examples were built, 1950
G. Lauxmann was one of many small agricultural-machinery workshops that, in the immediate post-war years in Germany, built their own tractors in very small numbers to meet farming's demand for motorised drawbar power while the larger manufacturers had not yet fully rebuilt their capacity. The 22 PS is an example of this small-batch production.
Read on 3 more paragraphs
The 22 PS is powered by a water-cooled two-cylinder diesel engine of 2,360 cc, producing 22 hp, or 16.2 kW, driving the rear wheels through a gearbox with four forward gears and one reverse. At a weight of 1,230 kg, it is a light to medium tractor for smaller farms; according to the register, only 4 examples of this machine were built.
A two-cylinder diesel engine with rear-wheel drive only and a simple four-speed gearbox matched the technical standard of smaller tractors in the early 1950s, built for tillage with light implements, running a power take-off at standard speed, and hauling small trailer loads on the owner's own yard and neighbouring fields.
When buying such a rare tractor, the first question is whether a surviving example can be found at all and whether its history can be traced. Technically, worth checking are the condition of the diesel engine's injection pump and injectors, wear in the clutch and gearbox, and the frame and rear axle for rust and cracks; spare parts for such a small maker are practically unavailable on the open market and would have to be made individually.
Sources: SpecCodex-Register: Kennwerte des Modells G. Lauxmann 22 PS
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 22 hp (16.2 kW)correct |
| Cylinders | 2correct |
| Displacement | 2,360 cm³correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Unladen weight | 1,230 kgcorrect |
|---|
Drivetrain and chassis
| Drive | rear-wheel drivecorrect |
|---|---|
| Gearbox | 4V+1Rcorrect |
Origin and approval
| Units built | 4correct |
|---|
Where this model stands
Power-to-weight ratio: 13.2 kW/t (16 kW / 1.2 t)
Power class: Compact (< 40 hp)
Stronger than 9% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the G Lauxmann 22 PS have?
The G Lauxmann 22 PS delivers 22 hp.
How much does the G Lauxmann 22 PS weigh?
The unladen weight is 1,230 kg.
What engine does the G Lauxmann 22 PS have?
2 cylinders, 2,360 cm³ displacement, Diesel.
When was the G Lauxmann 22 PS built?
Production years: 1950.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
