Fuzhou Hailin Power – other nonroad diesel engines: the collective page of the single-cylinder small diesels HL178FA and HL186FV from Fujian, 4 to 6 kW, Interim Tier 4
This page gathers the Fuzhou Hailin Power nonroad diesel engines the register could not assign to a named range from the US EPA certification data. Fuzhou Hailin Power is a Chinese maker of small diesel engines based in Fuzhou, Fujian province; the type designations HL178FA and HL186FV follow the 178F/186F frame-size naming common in this market segment for air-cooled single-cylinder small diesels, and the EPA engine-family code shows a displacement of 0.435 litres for both versions.
Read on 3 more paragraphs
The register lists here 2 versions with 4 to 6 kW rated output at 3,600 rpm, from a single cylinder with a 78 to 86 mm bore and 64 to 75 mm stroke – with a stroke-to-bore ratio under 1, a short-stroke design. The engines carry direct injection, run on low-sulphur diesel (300 to 500 ppm) and reach maximum torques of 10.6 to 16.7 Nm at 3,600 rpm. They were certified to the Interim Tier 4 stage, for use outside California only.
Small, high-speed single-cylinder diesel engines of this power class under 8 kW classically drive portable generator sets, water pumps and simple construction equipment; the Interim Tier 4 emission stage marks a transitional step in US nonroad engine emission regulation before the final Tier 4 Final stage.
When buying used, on these single-cylinder engines the condition of the cooling fins and fan wheel, compression, and the condition of the injection pump and nozzle matter; uneven running often points to wear in the injection system. Spares run through Hailin's Chinese distribution.
Sources: SpecCodex register, model data: Fuzhou Hailin Power (weitere Nonroad-Dieselmotoren)
Technical data
Engine
| Engine family | CFHML0.435CHcorrect |
|---|---|
| Fuel | 300-500 ppm Low Sulfur Dieselcorrect |
| Rated output | 4 kWcorrect |
| Power band | kW<8correct |
| Rated speed | 3,600 rpmcorrect |
| Maximum torque | 10.6 N·mcorrect |
| Speed at max. torque | 3,600 rpmcorrect |
| Cylinders | 1correct |
| Cylinder layout | in linecorrect |
| Bore | 78 mmcorrect |
| Stroke | 64 mmcorrect |
| Operating cycle | four-stroke dieselcorrect |
| Injection | direct injectioncorrect |
| Aspiration | naturally aspiratedcorrect |
| Emissions stage | Interim Tier 4correct |
Origin and approval
| Sales region | USA excluding Californiacorrect |
|---|
Frequently asked questions
How much power does the Fuzhou Hailin Power HL178FA have?
The Fuzhou Hailin Power HL178FA delivers 4 kW.
When was the Fuzhou Hailin Power HL178FA built?
Production years: 2011-2012.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
