Ford 901 Powermaster
Built: 1958–1962 · Series: 901er Baureihe
More machines from model year 1958
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Ford 901 Powermaster: water-cooled four-cylinder tractor with petrol, LPG or diesel engine, 46.1 kW and 1,517 kg weight, built 1958 to 1962
Ford was an American vehicle manufacturer whose tractor division built its own farm machinery before it was sold to the Italian Fiat group in 1991 and absorbed into New Holland. The 901 Powermaster formed the top end of the 901 series and, like the other models of this generation, was offered with a choice of petrol, LPG or diesel engine.
Read on 3 more paragraphs
The 901 Powermaster is powered by a water-cooled four-cylinder engine, producing 62.6 hp, or 46.1 kW, and 225 Nm of torque at 2,000 to 2,200 rpm. At a weight of 1,517 kg, a length of 3,353 mm, a height of 1,671 mm and a width of 1,821 mm, with a wheelbase of 2,167 mm, it is the most powerful example of its series, with a top speed of 28 km/h.
As the strongest four-cylinder model in its line, the Powermaster was built for tillage with larger implements, for work with heavier trailers and for power-take-off tasks demanding greater force. The choice between three fuel types allowed farms to match the drivetrain to whichever supply was available or most economical.
When buying a 901 Powermaster secondhand, the first thing that matters is which of the three fuel types the particular machine runs on, since the carburettor, vaporiser and injection pump are fundamentally different assemblies. Also worth checking are wear in the clutch and gearbox from the higher output, the cooling system, and corrosion on sheet-metal and frame parts.
Sources: SpecCodex-Register: Kennwerte des Modells Ford 901 Powermaster
Technical data
Engine
| Fuel | Benzin/LPG/Dieselcorrect |
|---|---|
| Power | 62.6 hp (46.1 kW)correct |
| Rated speed | 2.000/2.200 rpmcorrect |
| Torque | 225 Nmcorrect |
| Speed at max. torque | 1,600 rpmcorrect |
| Cylinders | 4correct |
| Bore | 99.06 mmcorrect |
| Stroke | 91.44 mmcorrect |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 3,353 mmcorrect |
|---|---|
| Width | 1,821 mmcorrect |
| Height | 1,671 mmcorrect |
| Wheelbase | 2,167 mmcorrect |
| Ground clearance | 722 mmcorrect |
| Unladen weight | 1,517 kgcorrect |
Drivetrain and chassis
| Drive | rear-wheel drivecorrect |
|---|---|
| Gearbox | 4 V/1 R or 10 V/2 Rcorrect |
| Front tyres | 5.50-16 ASFcorrect |
| Rear tyres | 12.00-28 AScorrect |
| Top speed | 28 km/hcorrect |
Where this model stands
Power-to-weight ratio: 30.4 kW/t (46 kW / 1.5 t)
Power class: Universal (40–100 hp)
Stronger than 44% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Ford 901 Powermaster have?
The Ford 901 Powermaster delivers 62.6 hp.
How much does the Ford 901 Powermaster weigh?
The unladen weight is 1,517 kg.
What engine does the Ford 901 Powermaster have?
4 cylinders, Benzin/LPG/Diesel.
How fast does the Ford 901 Powermaster go?
Top speed is 28 km/h.
What are the dimensions of the Ford 901 Powermaster?
3,353 mm × 1,821 mm × 1,671 mm.
When was the Ford 901 Powermaster built?
Production years: 1958–1962.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
