Fiat HYMER 614
Built: 2004 · Series: HYMER
More machines from model year 2004
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Fiat Hymer – motorhomes on the Ducato base outside the named ranges from the B-Class to the alcove layout: four-cylinder diesel engines, 2.5 to 2.8 litres displacement
This page gathers Hymer motorhomes built on Fiat chassis that the register could not assign to a named range. Hymer was founded in 1957 by Erwin Hymer in Bad Waldsee in Upper Swabia and is regarded as one of the pioneers of European motorhome building; the Fiat Ducato, since its introduction in 1981, alongside the Fiat 242/238, has been one of the industry's most widely used base vehicles. Hymer's B-Class denotes integrated and semi-integrated motorhomes in which the living body extends over the cab, as in the B 524, B 544 or B 644; the Dutch model name Kampeerauto points to that market's registration.
Read on 3 more paragraphs
The register lists here 15 versions with displacements from 2,500 to 2,800 cm³ from four-cylinder diesel engines, unladen weights from 2,240 to 3,125 kg, gross weights from 3,100 to 3,500 kg and widths from 2,210 to 2,350 mm.
Alongside Hobby, Knaus, Dethleffs and Bürstner, Hymer is one of the leading motorhome makers; the base on the Fiat Ducato, thanks to its wide distribution, ensures good workshop coverage even away from Hymer's own dealers.
On a used purchase, damp in the body and around roof hatches, the condition of the chassis and towbar, rust on the Fiat chassis, and on the older diesel engines the condition of the injection pump and turbocharger count; parts for the body run through Hymer, for the chassis through the Fiat Professional network.
Sources: SpecCodex register, model data: Fiat Hymer, Hymer (manufacturer), Zulassungsdaten RDW (Niederlande)
Technical data
Engine
| Cylinders | 4correct |
|---|---|
| Displacement | 2,800 cm³correct |
Dimensions and weights
| Width | 2,280 mmcorrect |
|---|---|
| Wheelbase | 3,780 mmcorrect |
| Unladen weight | 3,125 kgcorrect |
| Gross vehicle weight | 3,500 kgcorrect |
Drivetrain and chassis
| Wheels | 4correct |
|---|
Frequently asked questions
How much does the Fiat HYMER 614 weigh?
The unladen weight is 3,125 kg.
What is the gross vehicle weight of the Fiat HYMER 614?
3,500 kg.
What engine does the Fiat HYMER 614 have?
4 cylinders, 2,800 cm³ displacement.
When was the Fiat HYMER 614 built?
Production years: 2004.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 9 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
