Fendt FARMER 309 C

Built: 2004 · Series: Farmer

More machines from model year 2004

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

With the FARMER 309 C, Fendt offers a model from the Farmer series. Production: 2004. The engine delivers 70 kW, with a displacement of 3,190 cm³. The unladen weight is 4,110 kg. The gross vehicle weight is 7,000 kg. The Farmer series covers 34 models. Rated output within it ranges from 18.3 to 90 kW; the FARMER 309 C sits in the upper part of that range with 70 kW. Its immediate neighbours are the Farmer 310LSA below it with 67 kW and the Farmer 309 CA above it with 74 kW. Unladen weight within it ranges from 1,500 to 4,850 kg; here the FARMER 309 C sits in the upper part of that range with 4,110 kg. 1545 Fendt models across 89 series are on record.

Fendt Farmer – Base Name Spanning Several Decades, 1963 Into the 2000s: two- to four-cylinder diesels with 18.3 to 82 kW, 1,700 to 4,314 cm³ displacement, air- and water-cooled

Fendt used the name Farmer as a base designation for tractors across several decades, documented in the register from the 1Z in 1963 to Farmer models from 2009. Output of the recorded models ranges from 18.3 to 82 kW, using two- to four-cylinder engines with displacement from 1,700 to 4,314 cm³.

Read on 3 more paragraphs

Recorded operating weight runs from 1,500 to 4,850 kg, wheelbase from 1,775 to 2,333 mm, and top speed of the listed models spans 19.6 to 40 km/h. This wide spread reflects the fact that both early post-war models and modern cabbed tractors with higher travel speeds carried the Farmer name.

At Fendt, the Farmer name consistently denoted the mid power class between the more compact models and the large Favorit tractors. For a used Farmer tractor, the exact generation matters most, as technology and equipment changed fundamentally over this long span.

The two-speed PTO with 540 and 1,000 rpm only became widespread in Europe from the 1970s; early 1960s Farmer models therefore usually had only the single-speed 540 rpm PTO, while later model years offered both speeds. The three-point hitch matched category I at the lower end of the power range and already category II under ISO 730 at the upper end above 55 kW. The exact category therefore follows from the model year rather than the power rating alone, since Fendt introduced the change model by model.

Sources: SpecCodex register, model data: Fendt Farmer, Fendt

Technical data

Engine

Power70 kWcorrect
Displacement3,190 cm³correct

Dimensions and weights

Unladen weight4,110 kgcorrect
Gross vehicle weight7,000 kgcorrect

Where this model stands

Power-to-weight ratio: 17 kW/t (70 kW / 4.1 t)

Power class: Universal (40–100 hp)

Stronger than 63% of the tractors in the register — out of 15,663 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Fendt FARMER 309 C have?

The Fendt FARMER 309 C delivers 70 kW.

How much does the Fendt FARMER 309 C weigh?

The unladen weight is 4,110 kg.

What is the gross vehicle weight of the Fendt FARMER 309 C?

7,000 kg.

What engine does the Fendt FARMER 309 C have?

3,190 cm³ displacement.

When was the Fendt FARMER 309 C built?

Production years: 2004.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 5 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
