Euclid R32
Series: Euclid Rock Truck
The Euclid R32 belongs to the Euclid Rock Truck series. The engine delivers 406.6 hp (299 kW), has 6 cylinders, with a displacement of 12,000.2 cm³. Torque is 1,599.9 Nm. Rated speed is 2,100 rpm. The wheelbase measures 3,651.5 mm. Ground clearance is 451.1 mm. Top speed is 57 km/h. The tank holds 600.4 litres. Maximum torque is reached at 1,200 rpm. The hydraulic tank holds 75.3 litres. The cooling system holds 70 litres. The oil fill is 37.1 litres. The electrical system runs on 24 V. The engine fitted is the TD 122KE. Tyre size: 18,00-25/32. The Euclid Rock Truck series covers 4 models. Rated output within it ranges from 406.6 to 937.8 hp; the R32 sits at the bottom of that range with 406.6 hp. Its immediate neighbours are the R50 above it with 616.4 hp. 4 Euclid models are on record. The model is listed under Mining equipment. 21 verified figures from 1 source are on file.
Technical data
Engine
| Engine model | TD 122KEcorrect |
|---|---|
| Power | 406.6 hp (299 kW)correct |
| Rated speed | 2,100 rpmcorrect |
| Torque | 1,599.9correct |
| Speed at max. torque | 1,200 rpmcorrect |
| Cylinders | 6correct |
| Displacement | 12,000.2 cm³correct |
| Aspiration | turbochargedcorrect |
| Coolant capacity | 70 lcorrect |
| Engine oil capacity | 37.1 lcorrect |
Dimensions and weights
| Length | 8,037.6correct |
|---|---|
| Width | 3,602.7correct |
| Wheelbase | 3,651.5correct |
| Ground clearance | 451.1correct |
Drivetrain and chassis
| Gearbox type | planetarycorrect |
|---|---|
| Tyre size | 18.00-25/32correct |
| Top speed | 57 km/hcorrect |
| System voltage | 24 Vcorrect |
Working data
| Hydraulic oil capacity | 75.3 lcorrect |
|---|---|
| Fuel tank capacity | 600.4 lcorrect |
Frequently asked questions
How much power does the Euclid R32 have?
The Euclid R32 delivers 407 hp.
What engine does the Euclid R32 have?
6 cylinders, 12,000 cm³ displacement.
How fast does the Euclid R32 go?
Top speed is 57 km/h.
What are the dimensions of the Euclid R32?
8,038 mm × 3,603 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
