Doosan DA40-5
Series: Doosan Articulated Dump Truck
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Doosan articulated dump trucks – the DA30-5 and DA40-5 with Scania engines, 269.9 to 360.2 kW, 1,872.4 to 2,372.7 Nm torque
This page gathers the articulated dump trucks DA30-5 and DA40-5 from Doosan, the South Korean construction-equipment brand. Doosan offers articulated dump trucks alongside its core line of excavators and wheel loaders, giving earthmoving customers a consistent equipment range. The "DA" designation stands for Doosan Articulated, the following number the approximate payload in tonnes, and the "-5" suffix the fifth model generation of this range.
Read on 3 more paragraphs
The register lists here 2 versions at 269.9 to 360.2 kW from the Scania DC9 and DC13 engines with 9,301.3 to 12,701.6 cm³ displacement, lengths from 9,558.5 to 10,591.8 mm, heights from 3,560 to 3,850 mm and torque figures from 1,872.4 to 2,372.7 Nm.
Articulated dump trucks haul large volumes of material across unpaved ground in open-pit mining, earthworks and road construction, where the articulated steering joint keeps the machine mobile at full load; Doosan competes here with its Scania engines alongside the established brands Caterpillar, Volvo and Bell.
On used examples, operating hours and the condition of the Scania engine, wear on the dump-body mounting and tipping cylinders, the condition of the articulation joints, and tyres and brakes all matter; parts for the engine run through the Scania service network, and for the body and chassis through Doosan importers.
Sources: SpecCodex register, model data: Doosan Articulated Dump Truck
Technical data
Engine
| Engine make | Scaniacorrect |
|---|---|
| Engine model | DC 13correct |
| Power | 499.8 hp (360.2 kW)correct |
| Rated speed | 1,900 rpmcorrect |
| Torque | 2,372.7 Nmcorrect |
| Speed at max. torque | 1,300 rpmcorrect |
| Cylinders | 6correct |
| Displacement | 12,701.6 cm³correct |
| Coolant capacity | 50.3 lcorrect |
| Engine oil capacity | 44.3 lcorrect |
Dimensions and weights
| Length | 10,591.8 mmcorrect |
|---|---|
| Height | 3,850 mmcorrect |
Drivetrain and chassis
| Forward gears | 8correct |
|---|---|
| Reverse gears | 4correct |
| Top speed | 55 km/hcorrect |
Working data
| Fuel tank capacity | 530.3 lcorrect |
|---|
Other data
| System voltage | 24 Vcorrect |
|---|
Frequently asked questions
How much power does the Doosan DA40-5 have?
The Doosan DA40-5 delivers 500 hp.
What engine does the Doosan DA40-5 have?
6 cylinders, 12,702 cm³ displacement.
How fast does the Doosan DA40-5 go?
Top speed is 55 km/h.
What are the dimensions of the Doosan DA40-5?
10,592 mm × 3,850 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
