Dodge RAM 1500 TRX

Built: 2021-2022 · Series: RAM

More machines from model year 2021

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The RAM series from Dodge includes the RAM 1500 TRX. Production: 2021-2022. The engine delivers 523 kW, has 8 cylinders, with a displacement of 6,166 cm³. The vehicle is 5,780 mm long and 2,240 mm wide. The unladen weight is 2,810 kg. The wheelbase measures 3,680 mm. Top speed is 89 km/h. The gross vehicle weight is 3,539 kg. The vehicle runs on 4 wheels. The gearbox offers 8 gears. The RAM series covers 273 models. Rated output within it ranges from 109.4 to 523 kW; the RAM 1500 TRX sits at the top of that range with 523 kW. Its immediate neighbours are the RAM SLT 2500 QUAD CAB PICKUP below it with 325 kW. Unladen weight within it ranges from 2,114 to 5,060 kg; here the RAM 1500 TRX sits in the lower part of that range with 2,810 kg. 1343 Dodge models across 29 series are on record.

RAM 1500, 2500, 3500 — the number is a payload in pounds: Stellantis' American pick-up range with HEMI V8 and Cummins six-cylinder diesel engines

The figures 1500, 2500 and 3500 are not model names but a legacy of measurement: they originally denoted payload in American pounds. The principle has held — the higher the number, the greater the payload. In kilograms, a 1500 carries around 700 kg, a 2500 about 1,200 kg and a 3500 roughly 1,700 kg.

Read on 4 more paragraphs

The difference is not only on paper, though. Axles, transmissions and frame are consistently stronger on the 2500 and 3500 than on the 1500. That explains why the 1500 is regarded as a comfortable everyday vehicle and the heavy models as working tools — they share a name, not a substance.

The engines divide the range too. The 6.7-litre Cummins six-cylinder turbodiesel is available only in the 2500 and 3500; it was never offered in the 1500, nor was the 6.4-litre HEMI. The HEMI name denotes no series but a combustion chamber shape: hemispherical, a design feature of Chrysler V8s for decades.

Anyone assessing a vehicle should therefore read model year and engine together. For the 2025 model year the HEMI V8 in the regular 1500 range was replaced by Hurricane-family inline sixes of up to 540 hp — the same type number, a fundamentally different machine.

Ram models registered in Europe, with gross vehicle weights from 3,499 to 8,846 kg, span from the boundary of class N1 into class N2 (3.5 to 12 t); above 3.5 t, commercial use requires a category C1 driving licence, a tachograph and compliance with driving and rest times, plus a toll in several countries. Unlike the heavy Class 8 tractor units of the same model family in the US, the Ram remains, technically, a rigid vehicle with a fixed bed, not a tractor unit.

Sources: SpecCodex register, model data: Dodge Ram

Technical data

Engine

Power523 kWcorrect
Cylinders8correct
Displacement6,166 cm³correct

Dimensions and weights

Length5,780 mmcorrect
Width2,240 mmcorrect
Wheelbase3,680 mmcorrect
Unladen weight2,810 kgcorrect
Gross vehicle weight3,539 kgcorrect

Drivetrain and chassis

Gears8correct
Wheels4correct
Top speed89 km/hcorrect

Where this model stands

Power-to-weight ratio: 186.1 kW/t (523 kW / 2.8 t)

Stronger than 99% of the trucks in the register — out of 25,242 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Dodge RAM 1500 TRX have?

The Dodge RAM 1500 TRX delivers 523 kW.

How much does the Dodge RAM 1500 TRX weigh?

The unladen weight is 2,810 kg.

What is the gross vehicle weight of the Dodge RAM 1500 TRX?

3,539 kg.

What engine does the Dodge RAM 1500 TRX have?

8 cylinders, 6,166 cm³ displacement.

How fast does the Dodge RAM 1500 TRX go?

Top speed is 89 km/h.

What are the dimensions of the Dodge RAM 1500 TRX?

5,780 mm × 2,240 mm.

When was the Dodge RAM 1500 TRX built?

Production years: 2021-2022.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
