Discovery Energy LDW 1003/E4
Built: 2012 · Series: LDW 1003
More machines from model year 2012
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Discovery Energy (Rehlko) LDW 1003 — the Lombardini/Kohler Three-Cylinder for Compact Equipment
The LDW 1003 is a water-cooled three-cylinder diesel with a belt-driven overhead camshaft; a factory figure lists output around 20.5 kW (28 hp). Typical applications include compact tractors, aerial platforms, concrete mixers, compact loaders, dumpers, farm machinery, generators and welders.
Read on 3 more paragraphs
The engine line originates with the Italian manufacturer Lombardini, acquired by Kohler in 2007, after which it was sold as the Kohler KDW1003/LDW1003. In May 2024 Kohler's engine and energy business was spun off as a standalone company (majority owner Platinum Equity, legal entity "Discovery Energy"), and in September 2024 the brand was renamed Rehlko.
The LDW 1003 appears across a wide range of compact mobile and stationary machinery, from agricultural equipment through construction gear to generator sets — a small diesel where compactness and a broad accessory program matter more than raw power per liter.
On a used unit, the exact variant code (e.g. B1/B4/E4/R/GE) is the key thing to check, since it denotes different injection, cooling and generator-interface configurations; matching the nameplate against the parts catalog helps avoid buying the wrong version.
Sources: SpecCodex register, model data: LDW 1003, - Coleman's: Kohler KDW1003 Multipurpose Diesel Engine, - Rehlko: Kohler Energy is Now Rehlko, - Platinum Equity: Kohler Energy Rebrands as Rehlko
Technical data
Engine
| Engine family | CKHXL1.37SF1correct |
|---|---|
| Engine families | CKHXL1.37SF1correct |
| Fuel | 7-15 ppm Ultra Low Sulfur Dieselcorrect |
| Rated output | 18 kWcorrect |
| Power band | 8<=kW<19correct |
| Rated speed | 3,600 rpmcorrect |
| Maximum torque | 62 N·mcorrect |
| Speed at max. torque | 2,100 rpmcorrect |
| Cylinders | 3correct |
| Cylinder layout | in linecorrect |
| Bore | 75 mmcorrect |
| Stroke | 77.6 mmcorrect |
| Operating cycle | four-stroke dieselcorrect |
| Injection | indirect injectioncorrect |
| Aspiration | naturally aspiratedcorrect |
| Emissions stage | Tier 4 (Final or Phase In)correct |
Origin and approval
| Built from | 2012correct |
|---|---|
| Built to | 2012correct |
| Model year from | 2012correct |
| Model year to | 2012correct |
| Sales region | bothcorrect |
Frequently asked questions
How much power does the Discovery Energy LDW 1003/E4 have?
The Discovery Energy LDW 1003/E4 delivers 18 kW.
When was the Discovery Energy LDW 1003/E4 built?
Production years: 2012.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
