Davey Water Products 862

Series: Other models

The Davey Water Products 862 is a three-phase induction motor built by Davey Water Products. The rated output is 2.2 kW. The motor is two-pole, which at 50 Hz gives a synchronous speed of 3,000 rpm. The rated voltage is 415 V. The protection class is IP56. The efficiency is 85.8 per cent at full load, 85.9 per cent at 75 per cent load and 83.9 per cent at half load. The motor is built in Australia. The data is based on the Australian MEPS registration under the GEMS Determination 2012; measured to AS 1359.102.1:1997. Rated output across the Davey Water Products range ranges from 1.9 to 3.2 kW; the 862 sits in the lower part of that range with 2.2 kW. Its immediate neighbours are the 866 below it with 1.9 kW and the 863 above it with 2.8 kW. 9 Davey Water Products models are on record.

Davey Water Products – other electric motors: the collective page of Australian pump motors outside the named ranges, 'Davey Design' frame, 1.9 to 3.2 kW, IP56, no High Efficiency classification

This page gathers the Davey Water Products electric motors the Australian energy-efficiency register (GEMS/MEPS) could not assign to a named range. Davey Water Products is the full company name of the Australian pump and drive technology maker headquartered in Scoresby, Victoria. The model numbers in the register – 858, 859, 861 to 866, and a collective entry recorded as 8** – are plain item numbers; here too, the register consistently records the manufacturer's own designation 'Davey Design' as the frame size.

Read on 3 more paragraphs

The register lists here 9 versions with 1.9 to 3.2 kW, at an efficiency of 85.1 to 87% at full load and 85.4 to 87.5% at 75% load. Protection is uniformly IP56, manufacturing is exclusively in Australia. Testing mostly followed the 2012 GEMS determination (8 of 9 motors) and test method B; none of the nine motors carries a documented High Efficiency classification.

The motors in this group directly drive compact household pumps and small booster installations; the versions tested mostly under the older 2012 GEMS standard represent the established base offering in Davey's pump programme.

When buying used, bearing condition and a checked insulation resistance of the winding, corrosion on the housing and fan cover, the condition of the shaft seal towards the pump, and a legible nameplate with model number matter; since there is no documented High Efficiency classification, it is worth comparing actual current draw against newer models before buying. Spares run through Davey's Australian distribution.

Sources: SpecCodex register, model data: Davey Water Products (weitere Modelle, MEPS-Registrierungen), Davey Water Products (manufacturer)

Technical data

Engine

Rated output	2.2 kWcorrect

Electrical data

Rated voltage	415 Vcorrect
Number of poles	2correct
Protection class	IP56correct
Frame size	Davey Designcorrect
Mounting (IEC 60034-7)	Davey designcorrect
Efficiency at full load	85.8 %correct
Efficiency at 75 % load	85.9 %correct
Efficiency at half load	83.9 %correct

Origin and approval

Country of manufacture	Australiacorrect

Other data

Standard applied	Greenhouse and Energy Minimum Standards (Three Phase Electric Motors) Determination 2012correct
Test method	AS 1359.102.1:1997correct

Frequently asked questions

How much power does the Davey Water Products 862 have?

The Davey Water Products 862 delivers 2.2 kW.

What to check before buying

Match the data plate against the order: frame size, mounting and rating have to agree.
Check the ingress rating against the installation site — outdoors or in dust the demands differ.
Hold the mounting form and dimensions against the existing seat before ordering.
The pole count sets the speed — when replacing an older unit, compare this first.
For used units, ask about winding condition and bearing play.
Ask about parts availability for this series — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
