Cuppers MA 20 L
Built: 1998-2012 · Series: MA
More machines from model year 1998
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Cuppers MA – lighter trailer range: 7 versions, unladen weight from 2,820 to 9,420 kg, gross weight from 11,000 to 24,000 kg, lengths of up to just over 10 metres
Cuppers builds a range of commercial trailers under the designation MA, brought together on this page. All model names consist of the code MA, a two-digit number from 11 to 24, and a consistently appended letter L, with one version additionally carrying a preceding A as in MA 24 AL; the notation varies between MA 12 L with a space and MA 12L without a space before the L.
Read on 3 more paragraphs
The register lists here 7 versions with unladen weights from 2,820 to 9,420 kg at a gross weight of 11,000 to 24,000 kg. Lengths range from 8,420 to 10,240 mm, and widths from 2,400 to 2,550 mm.
With gross weights up to 24 tonnes, the MA range sits in the lighter to medium segment of the trailer class and thus covers a different need than the heavy long-haul trailers of around 40 tonnes, for instance in regional freight transport or for smaller loads. The spread of unladen weights from under 3 to over 9 tonnes shows a wide field from the light to the sturdier version within the same range.
When buying a used trailer of this range, check the frame and drawbar for corrosion and deformation, the condition of the axles and braking system, the operation of the lighting, and on the lighter versions also the condition of the floor panels or load area. Wear parts are available through the general commercial-vehicle parts trade, and on older examples it is also worth checking any retrofitted electrical and braking equipment.
Sources: SpecCodex register, model data: Cuppers MA
Technical data
Dimensions and weights
| Length | 9,970 mmcorrect |
|---|---|
| Width | 2,540 mmcorrect |
| Wheelbase | 7,000 mmcorrect |
| Unladen weight | 5,260 kgcorrect |
| Gross vehicle weight | 20,000 kgcorrect |
Drivetrain and chassis
| Top speed | 100 km/hcorrect |
|---|
Frequently asked questions
How much does the Cuppers MA 20 L weigh?
The unladen weight is 5,260 kg.
What is the gross vehicle weight of the Cuppers MA 20 L?
20,000 kg.
Up to what speed is the Cuppers MA 20 L approved?
Approved up to 100 km/h.
What are the dimensions of the Cuppers MA 20 L?
9,970 mm × 2,540 mm.
When was the Cuppers MA 20 L built?
Production years: 1998-2012.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 8 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
