Cummins X12455
Built: 2018-2019 · Series: Other models
More machines from model year 2018
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Cummins – other heavy-duty highway engines: the collective page of the B, ISB, ISV and ISX12 ranges outside the named models, diesel and natural-gas variants, 200 to 500 kW, model years 2013 to 2026
Cummins Inc. of Columbus, Indiana, founded in 1919, is one of the largest independent makers of diesel and gas engines for heavy commercial vehicles worldwide. This page gathers the on-highway engines the register could not assign to a named range, from the mid-duty B6.7N range through the ISB and ISV5.0 models to the heavy ISX12 range for long-haul trucking, plus the natural-gas variants marked with a G, ISBG and ISLG; the ISB, ISL and ISX prefixes traditionally denote different Cummins build sizes and duty classes.
Read on 3 more paragraphs
The register lists here 67 versions with 200 to 500 kW rated output at 1,761 to 3,200 rpm, model years 2013 to 2026, with torques from 520 to 1,700 Nm at 1,000 to 1,600 rpm. Among the diesel versions direct injection (54) prevails over electronic direct injection (7), while six versions running on compressed or liquefied natural gas use throttle-body injection, typical of spark-ignited gas engines.
The ISX12 range is Cummins' flagship for long-haul tractor units, while the B6.7N engines drive medium-duty trucks and coaches; the ISBG and ISLG natural-gas variants target emission-sensitive fleets such as city buses and refuse trucks. In the North American heavy highway-engine market, Cummins competes chiefly with Detroit Diesel, PACCAR MX and the Volvo and Mack engines.
On a used purchase, mileage and service records count, on the diesel variants the condition of the injection pump or injectors and turbocharger, on the gas engines the condition of the gas system and spark plugs in place of a glow or pre-heat system, and depending on model year the exhaust aftertreatment with particulate filter and SCR catalyst; spare parts run through the dense Cummins dealer network.
Sources: Kennwerte der Modelle Cummins (weitere Heavy-Duty-Straßenmotoren), Cummins Inc. (Hersteller)
Technical data
Engine
| Engine code | 4814; FR20750correct |
|---|---|
| Engine family | KCEXH0721XAGcorrect |
| Engine families | KCEXH0721XAG; JCEXH0721XAGcorrect |
| Fuel | 7-15 ppm ultra low sulfur dieselcorrect |
| Rated output | 455 hpcorrect |
| Rated speed | 1,761 rpmcorrect |
| Maximum torque | 1,700 ft·lbfcorrect |
| Speed at max. torque | 1,000 rpmcorrect |
| Displacement | 11,800 cm³correct |
| Displacement | 11.8 lcorrect |
| Operating cycle | dieselcorrect |
| Injection | direct injectioncorrect |
| Aspiration | turbochargedcorrect |
Origin and approval
| Version | 4814; FR20750correct |
|---|---|
| Built from | 2018correct |
| Built to | 2019correct |
| Model year from | 2018correct |
| Model year to | 2019correct |
| Sales region | USA certificationcorrect |
Other data
| Anwendungsbereich | Both Tractor and Vocationalcorrect |
|---|
Frequently asked questions
How much power does the Cummins X12455 have?
The Cummins X12455 delivers 455 kW.
What engine does the Cummins X12455 have?
11,800 cm³ displacement, 7-15 ppm ultra low sulfur diesel.
When was the Cummins X12455 built?
Production years: 2018-2019.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 22 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
