Cnh Steyr CVT 6175
Built: 2007–2009 · Series: CVT - Dritte Generation
More machines from model year 2007
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Steyr CVT third generation (2011–2014) – the stepless six-cylinders from St. Valentin: CVT 6140 to CVT 6210, the last digits as hp class, FPT six-cylinder of 6.7 litres with SCR, S-Control transmission, 104 to 157 kW
The Steyr CVT is the tractor with which the Austrian maker from St. Valentin brought the stepless transmission into the CNH group family: in 1999 Steyr presented the first CVT, whose S-Control transmission afterwards ran as CVX at Case IH and Auto Command at New Holland; the third generation of 2011 is the 6140 to 6210 range with the FPT engines to emission stage IIIB. The type logic: CVT marks the stepless transmission, 6 the six-cylinder series, the last digits the hp class – 6140 about 140 hp, 6160 160 hp, 6195 195 hp, 6210 about 210 hp with power boost – Profi and Multi are the smaller Steyr ranges with powershift. The engine in all models is the FPT NEF six-cylinder of 6.7 litres at 2,100 to 2,200 rpm, with SCR exhaust aftertreatment and approval for biodiesel, as the register notes; the CVT shares cab, front-axle suspension and operating concept with the Case IH Puma CVX from the same plant.
Read on 3 more paragraphs
The register lists 6 versions with 104 to 157 kW from the six-cylinder of 6,597 to 6,728 cm³, unladen weights from 6,390 to 7,200 kg, lengths from 4,775 to 5,017 mm, widths from 2,550 to 2,682 mm and heights from 3,042 to 3,090 mm.
Steyr is market leader in Austria and the CVT the tractor of contractors and grassland farms of the Alpine region; the fourth generation followed in 2014 with the CVT 6145 to 6240 range to emission stage IV.
On used tractors, operating hours, engine and SCR system, S-Control transmission (oil history, calibration), front-axle and cab suspension, hydraulics and electronics and parts supply through CNH count.
Sources: SpecCodex register, model data: Steyr CVT (dritte Generation), Steyr Traktoren (CNH, Hersteller, St. Valentin)
Technical data
Engine
| Fuel | Diesel / Biodieselcorrect |
|---|---|
| Power | 175 hp (129 kW)correct |
| Rated speed | 2,100 rpmcorrect |
| Cylinders | 6correct |
| Displacement | 6,597 cm³correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 4,785 mmcorrect |
|---|---|
| Width | 2,550 mmcorrect |
| Height | 3,042 mmcorrect |
| Wheelbase | 2,832 mmcorrect |
| Unladen weight | 6,770 kgcorrect |
Drivetrain and chassis
| Drive | four-wheel drivecorrect |
|---|---|
| Gearbox | continuously variablecorrect |
| Front tyres | 540 / 65 R 30correct |
| Rear tyres | 650 / 65 R 42correct |
| Top speed | 40 km/hcorrect |
Where this model stands
Power-to-weight ratio: 19.1 kW/t (129 kW / 6.8 t)
Power class: Large (100–180 hp)
Stronger than 88% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Cnh Steyr CVT 6175 have?
The Cnh Steyr CVT 6175 delivers 175 hp.
How much does the Cnh Steyr CVT 6175 weigh?
The unladen weight is 6,770 kg.
What engine does the Cnh Steyr CVT 6175 have?
6 cylinders, 6,597 cm³ displacement, Diesel / Biodiesel.
How fast does the Cnh Steyr CVT 6175 go?
Top speed is 40 km/h.
What are the dimensions of the Cnh Steyr CVT 6175?
4,785 mm × 2,550 mm × 3,042 mm.
When was the Cnh Steyr CVT 6175 built?
Production years: 2007–2009.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
