CMG HLE 112M-2
Series: HLE
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
CMG HLE – the Australian three-phase range for IEC frame sizes 112 to 132: 2.2 to 7.5 kW, two- to six-pole, made in China, IP55 without a GEMS High Efficiency rating
CMG is an Australian industrial-motor company selling three-phase motors and drive equipment into the Australian market; according to the register entries, manufacture is in China. The HLE range covers the mid-range IEC frame sizes and rounds out CMG's wider standard-motor programme with a compact base line. The nameplates of the eight motors listed here – such as HLE 112M-2 or HLE 132MB-6 – follow the IEC scheme of frame size, build-form code and pole count at the end of the designation.
Read on 3 more paragraphs
The register lists here eight versions with 2.2 to 7.5 kW, two- to six-pole, full-load efficiencies from 82.7 to 90.1% and at 75% load from 83.7 to 90.4%. Frame sizes run from 112 to 132 under IEC, protection is IP55 throughout, and rated voltage is 400 V. Mounting is in the full B3/B5/B14/B34/B35 set, with one motor's codes recorded in a different order. Testing followed the 2012 GEMS determination with test method B; none of the eight motors reaches a High Efficiency Level.
HLE motors in this power class are typical general-purpose drives for pumps, fans, compressors and conveying plant in the Australian industrial and commercial market, where CMG appears as a domestic brand alongside international suppliers such as WEG, TECO and ABB.
When buying used, bearing condition, a measured winding insulation resistance and any visible overheating marks at the terminal box and fan cover matter; the shaft and key should be free of play. A legible nameplate with frame size, pole count and efficiency figure aids identification. Spares and service run through CMG's distribution network in Australia.
Sources: SpecCodex register, model data: CMG HLE
Technical data
Engine
| Rated output | 4 kWcorrect |
|---|
Electrical data
| Rated voltage | 400 Vcorrect |
|---|---|
| Number of poles | 2correct |
| Protection class | IP55correct |
| Frame size | 112 M (foot)correct |
| Mounting (IEC 60034-7) | B3, B5, B35, B14, B34correct |
| Efficiency at full load | 88.7 %correct |
| Efficiency at 75 % load | 88.6 %correct |
| Efficiency at half load | 87.1 %correct |
Origin and approval
| Country of manufacture | Chinacorrect |
|---|
Other data
| Standard applied | Greenhouse and Energy Minimum Standards (Three Phase Electric Motors) Determination 2012correct |
|---|---|
| Test method | AS 1359.102.1:1997correct |
Frequently asked questions
How much power does the CMG HLE 112M-2 have?
The CMG HLE 112M-2 delivers 4 kW.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- Check the ingress rating against the installation site — outdoors or in dust the demands differ.
- Hold the mounting form and dimensions against the existing seat before ordering.
- The pole count sets the speed — when replacing an older unit, compare this first.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
