Chyun Tsen Motor HSW
Series: Other models
Chyun Tsen Motor HSW – a three-phase industrial motor rated at 11.2 kilowatts for pumps, machine tools and drives in trade and industry
Motors such as the HSW described here belong to the broad class of three-phase industrial motors in the mid power range, working on pumps, fans, compressors and machine tools across trades and industry.
Read on 3 more paragraphs
With a rated output of 11.2 kilowatts, the motor sits just above the common 11-kilowatt step, in a range that powers medium-sized pumps or machine-tool spindles. Motors of this power class already need a stronger mains connection and are usually protected by motor circuit breakers with thermal overload protection.
In industrial motors of this kind the squirrel-cage rotor is standard, since it runs with little maintenance and needs no slip rings. The number of poles sets the synchronous speed: at 50 hertz, two-pole motors turn at 3,000 revolutions per minute, four-pole motors at 1,500 and six-pole motors at 1,000, each slightly reduced by slip. Protection ratings follow IEC 60529 and mounting arrangements IEC 60034-7, for example a foot-mounted IM B3 motor or a flange-mounted IM B5 type. Running it from a frequency inverter raises the demands on insulation strength.
When buying secondhand, the rating plate is worth checking first: output, voltage, frequency and connection type should be legible and suitable. Turned by hand, the bearings should run smoothly, without play or noise, while an insulation test with an insulation-resistance tester reveals damp or damaged windings. The fan cover and terminal box deserve a second look, since corrosion or broken ribs point to a hard working life. If the motor has been rewound, that is worth raising openly before buying.
Sources: SpecCodex-Register: Kennwerte des Modells HSW
Technical data
Engine
| Rated output | 11.2 kWcorrect |
|---|
Dimensions and weights
| Weight | 115 kgcorrect |
|---|
Electrical data
| Rated voltage | 415 Vcorrect |
|---|---|
| Number of poles | 4correct |
| Protection class | IP54correct |
| Frame size | 160 M (foot)correct |
| Mounting (IEC 60034-7) | B3correct |
| Efficiency at full load | 90.9 %correct |
| Efficiency at 75 % load | 90.5 %correct |
| Efficiency at half load | 89.6 %correct |
Origin and approval
| Country of manufacture | Taiwancorrect |
|---|
Other data
| Standard applied | AS/NZS 1359.5:2004correct |
|---|---|
| Test method | IEC 60034-2-1 (Edition 2.0)correct |
Frequently asked questions
How much power does the Chyun Tsen Motor HSW have?
The Chyun Tsen Motor HSW delivers 11.2 kW.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- Check the ingress rating against the installation site — outdoors or in dust the demands differ.
- Hold the mounting form and dimensions against the existing seat before ordering.
- The pole count sets the speed — when replacing an older unit, compare this first.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
