Chevrolet C20 PICK-UP – specifications
Built: 1965-1975 · Series: C20
The C20 PICK-UP from Chevrolet is part of the C20 series. Production: 1965-1975. The engine has 8 cylinders, with a displacement of 5,700 cm³. The vehicle is 5,232 mm long and 2,000 mm wide. The unladen weight is 2,184 kg. The wheelbase measures 3,230 mm. The gross vehicle weight is 3,015 kg. The vehicle runs on 4 wheels. The gearbox offers 3 gears. The C20 series covers 21 models. Unladen weight within it ranges from 1,780 to 2,400 kg; the C20 PICK-UP sits in the upper part of that range with 2,184 kg. Its immediate neighbours are the C20 HD below it with 2,182 kg and the C20 DELUXE above it with 2,185 kg. Gross vehicle weight within it ranges from 2,500 to 3,500 kg; here the C20 PICK-UP sits in the middle of that range with 3,015 kg. 2857 Chevrolet models across 75 series are on record.
Data for the version built 1965-1975 · Data origin: Official register · sources
More machines from model year 1965
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Chevrolet C20 – the three-quarter-ton class of the C/K pickup range: V8 engines of 4.6 to 7.4 litres, trim lines from Custom Deluxe to Cheyenne and Silverado
The C20 formed the three-quarter-ton class in General Motors' C/K pickup range: C stood for rear-wheel drive (K for four-wheel drive), the number 10, 20 or 30 for the payload class between half a ton and a ton. Chevrolet built the range from 1960 to 1987 across several generations, with the third generation, known as the Square Body and built from 1973 to 1987 with its angular body, making up most of the vehicles captured here. The name additions mark the trim lines: Custom, Custom Deluxe and Scottsdale the simpler ones, Cheyenne and Cheyenne Super the mid-range, Silverado the upper trim; Fleetside and Stepside name the flush or the stepped load bed.
Read on 3 more paragraphs
The register lists here 21 versions with V8s of 4,600 to 7,439 cm³, unladen weights from 1,780 to 2,400 kg, gross weights from 2,500 to 3,500 kg, lengths from 4,420 to 5,550 mm and widths from 1,750 to 2,060 mm; power is recorded in the register as 97 kW.
The C20 was one of the best-selling pickups of its class in the US and Canada and served tradespeople, farmers and as a base for camper conversions; in Europe the vehicles arrived mostly as imports and are used there less often as everyday transport, more often as enthusiast vehicles.
On a used example from these model years, rust on the frame, load bed and wings, the condition of the carburettor or early injection, the automatic and transfer gearboxes on four-wheel-drive versions, and the brake system count; the V8 engines of this range are regarded as durable and can be fully supplied, if needed, through the US parts market.
Sources: SpecCodex register, model data: Chevrolet C20, Chevrolet (manufacturer)
Technical data
Engine
| Cylinders | 8correct |
|---|---|
| Displacement | 5,700 cm³correct |
Dimensions and weights
| Length | 5,232 mmcorrect |
|---|---|
| Width | 2,000 mmcorrect |
| Wheelbase | 3,230 mmcorrect |
| Unladen weight | 2,184 kgcorrect |
| Gross vehicle weight | 3,015 kgcorrect |
Drivetrain and chassis
| Gears | 3correct |
|---|---|
| Wheels | 4correct |
