Caterpillar D4H

Series: Caterpillar Skidder

Source: https://commons.wikimedia.org/w/index.php?curid=25364840 up
The D4H from Caterpillar is part of the Caterpillar Skidder series. The engine delivers 100.4 hp (67.1 kW), has 4 cylinders, with a displacement of 5,201.3 cm³. Rated speed is 2,200 rpm. The unladen weight is 12,380 kg. Ground clearance is 560.8 mm. The gearbox has 3 forward gears. There are also 3 reverse gears. Working pressure is 186.2 bar. The engine fitted is the 3,204. The Caterpillar Skidder series covers 20 models. Rated output within it ranges from 96.3 to 1,217.7 hp; the D4H sits at the bottom of that range with 100.4 hp. Its immediate neighbours are the D4H TSK Series II below it with 96.6 hp and the D5H TSK Series II above it with 122.4 hp. 1091 Caterpillar models across 47 series are on record. The model is listed under Forestry equipment. 15 verified figures from 1 source are on file.

Technical data

Engine

Engine model3,204correct
Power100.4 hp (67.1 kW)correct
Rated speed2,200 rpmcorrect
Cylinders4correct
Displacement5,201.3 cm³correct
Aspirationturbochargedcorrect

Dimensions and weights

Width2,462.8correct
Ground clearance560.8correct
Unladen weight12,380 kgcorrect

Drivetrain and chassis

Gearbox typepower shiftcorrect
Forward gears3correct
Reverse gears3correct

Working data

Hydraulic pressure186.2correct

Other data

Height3,163.8correct

Where this model stands

Power-to-weight ratio: 5.4 kW/t (67 kW / 12.4 t)

Stronger than 0% of the forestry equipment in the register — out of 111 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Caterpillar D4H have?

The Caterpillar D4H delivers 100 hp.

How much does the Caterpillar D4H weigh?

The unladen weight is 12,380 kg.

What engine does the Caterpillar D4H have?

4 cylinders, 5,201 cm³ displacement.
