Caterpillar 535C Grapple
Series: Caterpillar Skidder
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Technical data
Engine
| Engine model | C7 Acertcorrect |
|---|---|
| Power | 221 hp (152.1 kW)correct |
| Rated speed | 1,800 rpmcorrect |
| Speed at max. torque | 1,400 rpmcorrect |
| Cylinders | 6correct |
| Displacement | 7,193.9 cm³correct |
| Coolant capacity | 56.8 lcorrect |
| Engine oil capacity | 26.9 lcorrect |
Dimensions and weights
| Length | 7,626.1correct |
|---|---|
| Width | 3,398.5correct |
| Wheelbase | 3,535.7correct |
| Ground clearance | 533.4correct |
| Unladen weight | 18,043.9 kgcorrect |
Drivetrain and chassis
| Gearbox type | Countershaft powershift transmissioncorrect |
|---|---|
| Forward gears | 5correct |
| Reverse gears | 3correct |
| Tyre size | 30.5 x 32correct |
Working data
| Hydraulic oil capacity | 112 lcorrect |
|---|---|
| Hydraulic pressure | 209.9correct |
| Fuel tank capacity | 314.9 lcorrect |
Other data
| Height | 3,185.2correct |
|---|
Where this model stands
Power-to-weight ratio: 8.4 kW/t (152 kW / 18 t)
Stronger than 57% of the forestry equipment in the register — out of 111 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Caterpillar 535C Grapple have?
The Caterpillar 535C Grapple delivers 221 hp.
How much does the Caterpillar 535C Grapple weigh?
The unladen weight is 18,044 kg.
What engine does the Caterpillar 535C Grapple have?
6 cylinders, 7,194 cm³ displacement.
What are the dimensions of the Caterpillar 535C Grapple?
7,626 mm × 3,398 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
