Caterpillar 535B

Series: Caterpillar Skidder

Source: https://www.truck1.eu/construction-machinery/caterpillar/cat

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Caterpillar 535B belongs to the Caterpillar Skidder series. The engine delivers 202.8 hp (134.2 kW), has 6 cylinders, with a displacement of 7,239.8 cm³. The unladen weight is 16,919 kg. The wheelbase measures 3,554 mm. Ground clearance is 582.2 mm. The tank holds 314.9 litres. The gearbox has 5 forward gears. There are also 3 reverse gears. The hydraulic tank holds 123 litres. The cooling system holds 50 litres. The oil fill is 27.3 litres. The engine fitted is the Cat 3126 DITA diesel. Tyre size: 30,5 x 32. The Caterpillar Skidder series covers 20 models. Rated output within it ranges from 96.3 to 1,217.7 hp; the 535B sits at the bottom of that range with 202.8 hp. Its immediate neighbours are the 525C Grapple below it with 198.7 hp and the 535C Grapple above it with 221 hp. 1091 Caterpillar models across 47 series are on record. The model is listed under Forestry equipment. 17 verified figures from 1 source are on file.

Technical data

Engine

Engine modelCat 3126 DITA dieselcorrect
Power202.8 hp (134.2 kW)correct
Cylinders6correct
Displacement7,239.8 cm³correct
Coolant capacity50 lcorrect
Engine oil capacity27.3 lcorrect

Dimensions and weights

Width3,386.3correct
Wheelbase3,554correct
Ground clearance582.2correct
Unladen weight16,919 kgcorrect

Drivetrain and chassis

Forward gears5correct
Reverse gears3correct
Tyre size30.5 x 32correct

Working data

Hydraulic oil capacity123 lcorrect
Fuel tank capacity314.9 lcorrect

Other data

Height3,233.9correct

Where this model stands

Power-to-weight ratio: 7.9 kW/t (134 kW / 16.9 t)

Stronger than 49% of the forestry equipment in the register — out of 111 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Caterpillar 535B have?

The Caterpillar 535B delivers 203 hp.

How much does the Caterpillar 535B weigh?

The unladen weight is 16,919 kg.

What engine does the Caterpillar 535B have?

6 cylinders, 7,240 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
