Case New Holland TJ-330
Built: 2001–2002 · Series: TJ-Baureihe
More machines from model year 2001
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
New Holland TJ series (2002–2007) – the articulated tractors from Fargo as twins of the Case IH STX: TJ275 to TJ480, the number as hp class, six-cylinders of 8.3 to 14.9 litres, 202 to 353 kW, 14 to 20 t
The TJ range was New Holland's first articulated tractor after the merger with Case into CNH: as a condition of the 1999 merger New Holland had to sell its big-tractor brand Versatile with the Winnipeg plant to Buhler, and from 2002 the blue articulated tractors came from the Case IH plant in Fargo, North Dakota, the old Steiger plant – the TJs are technically the twins of the Case IH STX. The type logic: TJ marks the range, the number the hp class – TJ275 about 275 hp, TJ375 375 hp, TJ480 480 hp; the engines are the CNH six-cylinder of 8.3 litres in the small, Cummins QSM11 of 10.8 litres in the medium and Cummins QSX15 of 14.9 litres in the big models, the register span of 8,267 to 14,945 cm³ shows the three steps. The transmissions are 16-speed powershifts, the chassis articulated with four equal wheels, optionally on duals or triples.
Read on 3 more paragraphs
The register lists 9 versions with 202.3 to 353 kW from six-cylinders at 2,000 rpm rated speed, torque from 1,293 to 2,263 Nm, unladen weights from 14,422 to 20,251 kg, lengths from 7,010 to 7,558 mm, widths from 3,048 to 3,683 mm and heights from 3,480 to 3,810 mm.
The TJs are the tractors of the prairie: grain farms in Canada, the Dakotas and Australia with 15 metre seeders; in 2007 the T9000 range followed in the same logic, later the T9.
On used tractors, operating hours, the condition of engine and powershift, articulation joint and steering cylinders, axles and tyres (the most expensive item), hydraulic output and parts supply through CNH and Cummins are what count.
Sources: SpecCodex register, model data: New Holland TJ-Baureihe, New Holland Agriculture (manufacturer)
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 330 hp (242.7 kW)correct |
| Rated speed | 2,000 rpmcorrect |
| Torque | 1,460 Nmcorrect |
| Speed at max. torque | 1,402 rpmcorrect |
| Cylinders | 6correct |
| Displacement | 8,849 cm³correct |
| Bore | 114 mmcorrect |
| Stroke | 144.5 mmcorrect |
| Compression ratio | 16.6correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 7,558 mmcorrect |
|---|---|
| Width | 3,683 mmcorrect |
| Height | 3,631 mmcorrect |
| Wheelbase | 3,911 mmcorrect |
| Unladen weight | 14,649 kgcorrect |
Drivetrain and chassis
| Drive | four-wheel drivecorrect |
|---|---|
| Gearbox | 24 V/6 R or 16 V/2 Rcorrect |
| Front tyres | 480/80 R 46 AScorrect |
| Rear tyres | 480/80 R 46 AScorrect |
| Top speed | 30 km/hcorrect |
Origin and approval
| Construction | articulated framecorrect |
|---|
Where this model stands
Power-to-weight ratio: 16.6 kW/t (243 kW / 14.6 t)
Power class: Heavy (> 180 hp)
Stronger than 98% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Case New Holland TJ-330 have?
The Case New Holland TJ-330 delivers 330 hp.
How much does the Case New Holland TJ-330 weigh?
The unladen weight is 14,649 kg.
What engine does the Case New Holland TJ-330 have?
6 cylinders, 8,849 cm³ displacement, Diesel.
How fast does the Case New Holland TJ-330 go?
Top speed is 30 km/h.
What are the dimensions of the Case New Holland TJ-330?
7,558 mm × 3,683 mm × 3,631 mm.
When was the Case New Holland TJ-330 built?
Production years: 2001–2002.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
