Case New Holland T 9030

Built: 2007–2010 · Series: T 9000 er-Baureihe

More machines from model year 2007

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The T 9030 from Case New Holland is part of the T 9000er series. Production: 2007–2010. The engine delivers 385 hp (283.2 kW), has 6 cylinders, with a displacement of 12,880 cm³. Torque is 1,751 Nm. Rated speed is 2,000 rpm. The machine is 7,558 mm long, 3,050 mm wide and 3,818 mm high. The unladen weight is 18,951 kg. The wheelbase measures 3,911 mm. Top speed is 30 km/h. Transmission: 16 V/2 R. The engine is water-cooled. Tyres: front 480/80 R 46 AS, rear 480/80 R 46 AS. The fuel is Diesel/Biodiesel. The bore measures 135 mm. The stroke is 150 mm. The compression ratio is 16.5:1. Maximum torque is reached at 1,200 rpm. Construction: articulated frame. The T 9000 er-Baureihe series covers 4 models. Rated output within it ranges from 335 to 485 hp; the T 9030 sits in the lower part of that range with 385 hp. Its immediate neighbours are the T 9020 below it with 335 hp and the T 9040 above it with 435 hp. Unladen weight within it ranges from 14,649 to 19,892 kg; here the T 9030 sits in the upper part of that range with 18,951 kg. 84 Case New Holland models across 17 series are on record.

Case New Holland T9000 series – articulated large tractors from Fargo: T 9020 to T 9050 with a six-cylinder, up to 12.9-litre displacement, 246 to 357 kW and up to 19,892 kg unladen weight

The T9000 series is a register name from the Case New Holland (CNH) era for articulated large tractors built at the American plant in Fargo, North Dakota. The four models T 9020, T 9030, T 9040 and T 9050 are staggered by rising power through the last two digits of their designation and carry six-cylinder diesel engines that, according to the register, can run on both diesel and biodiesel.

Read on 3 more paragraphs

The register lists 4 versions with 246.4 to 356.7 kW from six-cylinders with 8,849 to 12,880 cm³ displacement. Unladen weights range from 14,649 to 19,892 kg at a uniform length of 7,558 mm, uniform width of 3,050 mm and uniform height of 3,818 mm; torque lies between 1,460 and 2,295 Nm at a uniform rated speed of 2,000 rpm.

As articulated large tractors with four-wheel drive, the T9000 series counts among the most powerful field tractors for large farms with very high draft-power needs, such as tillage of large field areas with wide cultivators, competing with comparable articulated tractors from Case IH Steiger and John Deere.

When buying used, the operating hours on the six-cylinder, the condition of the articulation joint and its hydraulic cylinders, the tightness of turbocharger and cooling system, and wear on the axles and wide tyres all matter. Spare parts run through the Case IH and New Holland dealer network.

Sources: SpecCodex register, model data: Case New Holland T9000er-Baureihe, New Holland Agriculture (manufacturer)

Technical data

Engine

Fuel	Diesel/Biodieselcorrect
Power	385 hp (283.2 kW)correct
Rated speed	2,000 rpmcorrect
Torque	1,751 Nmcorrect
Speed at max. torque	1,200 rpmcorrect
Cylinders	6correct
Displacement	12,880 cm³correct
Bore	135 mmcorrect
Stroke	150 mmcorrect
Compression ratio	16.5correct
Cooling	water-cooledcorrect

Dimensions and weights

Length	7,558 mmcorrect
Width	3,050 mmcorrect
Height	3,818 mmcorrect
Wheelbase	3,911 mmcorrect
Unladen weight	18,951 kgcorrect

Drivetrain and chassis

Drive	four-wheel drivecorrect
Gearbox	16 V/2 Rcorrect
Front tyres	480/80 R 46 AScorrect
Rear tyres	480/80 R 46 AScorrect
Top speed	30 km/hcorrect

Origin and approval

Construction	articulated framecorrect

Where this model stands

Power-to-weight ratio: 14.9 kW/t (283 kW / 19 t)

Power class: Heavy (> 180 hp)

Stronger than 99% of the tractors in the register — out of 15,663 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Case New Holland T 9030 have?

The Case New Holland T 9030 delivers 385 hp.

How much does the Case New Holland T 9030 weigh?

The unladen weight is 18,951 kg.

What engine does the Case New Holland T 9030 have?

6 cylinders, 12,880 cm³ displacement, Diesel/Biodiesel.

How fast does the Case New Holland T 9030 go?

Top speed is 30 km/h.

What are the dimensions of the Case New Holland T 9030?

7,558 mm × 3,050 mm × 3,818 mm.

When was the Case New Holland T 9030 built?

Production years: 2007–2010.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
Shift the gearbox cold and warm — jumps only show up at temperature.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
