Case IH MAGNUM 235 4WD
Series: MAGNUM
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
As a tractor, the Case IH MAGNUM 235 belongs to the Case IH 4WD Tractor series. 175.2 kW is what the six-cylinder engine gets out of 8.7 litres. Rated power is reached at 2,000 rpm.
Within the range, rated power spans from 93.2 to 399 kW; with 175 kW, the MAGNUM 235 sits in the lower third. Directly alongside are the Maxxum 140 PRO with 104 kW below and the Magnum 290 with 236 kW above.
Case IH Magnum 7100 and 7200 — the big six
The Magnum was presented in 1987 as successor to the International 50 in the standard tractor role; series production began in 1988. The first range carried the numbers 7110, 7120, 7130 and 7140 — four large tractors, later joined by a fifth model.
Read on 3 more paragraphs
What they share is the engine: a turbocharged six-cylinder of 8.3 litres. Rated power across the range ran from 155 to 230 hp, with peak output reaching up to 246 or 264 hp at the top. The rising number therefore maps the power step, not the machine size — all models share the same base tractor.
In 1997 the 7100 range became the 7200, again with five models, the 7250 closing it at the top. The Pro designation marks the revised version. Later came the MX Magnum range, with which Case IH carried the visually ageing concept forward.
For the used market this means a 7120 and a 7220 are closely related but roughly a decade apart. Comparing two offers, do not look at the number alone but at year and version — the figure describes a position in the range, not the age of the machine.
Sources: tractorbook, Landwirt.com, agrarheute
Technical data
Engine
| Power | 175.2 kWcorrect |
|---|---|
| Rated speed | 2,000 rpmcorrect |
| Cylinders | 6correct |
| Displacement | 8,701.5 cm³correct |
Drivetrain and chassis
| Forward gears | 19correct |
|---|---|
| Reverse gears | 4correct |
Working data
| Fuel tank capacity | 635.9 lcorrect |
|---|
Other data
| Height | 3,371.1correct |
|---|
Frequently asked questions
How much power does the Case IH MAGNUM 235 have?
The Case IH MAGNUM 235 delivers 175 kW.
What engine does the Case IH MAGNUM 235 have?
6 cylinders, 8,702 cm³ displacement.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 8 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
